COBRA Intelligent DC Servo Drive (Single-Axis)

COBRA series DC servo system is MOTEC’s latest intelligent servo system features integrated servo drive, motion controller and optional PLC function. It can be easily controlled by PC, Touch Panel, PLC or third party controllers via various control&communication mode. ARES DC intelligent servo system is a value for money products with high power density and abundant control features & functions. Cobra DC servo drive features very compact size and very high power density. COBRA DC servo drive offers single axis version and dual-axis version for customer’s choice.

Function and Features

― Integrated servo drive, motion controller and PLC

― Ladder diagram programming

― Support MOTECIAN, MODBUS, CANOPEN communication protocols

― Support RS232,RS485,CAN BUS

― 8 digital input, 5 digital output and 1 analog input

― Integrated T curve and S curve velocity profile generating function and PVT function

― Support serial magnetic encoder, incremental encoder, and absolute encoder

― Instruction set and DLL library available

― Network control mode, pulse/direction control mode, analog control mode, PWM control mode and PLC mode

― Multiple gain group real-time switching function

― Speed control/position control/torque control options

― 6Amp, 12Amp and 20Amp rated current models

― MOTIONSTUDIO configuration software and MOTIONPAINTER programming software.

―Integrated temperature protection, over-current protection, over-voltage protection, under-voltage protection, out of tolerance position protection, out of tolerance speed protection, I2T current protection, etc.

― PCB or Connector connecting options

Serial Magnetic Encoder is a quadrature encoder developed by MOTEC(China) based onRS485 communication protocol with 2.5MBPS data transfer rate and 16384 pulse per turnresolution。It has been widely accepted because of its simple connection, high reliability andhigh resolution features. The length of motors with serial magnetic encoder is also shorter than those with other feedback options.

All MOTEC DC servo motors can be ordered with resolver as feedback device. The working temperature of standard motors is -20℃ to 40℃ but motors with -40℃~55℃ working temperature are available for order. MOTEC DC servo motors are equipped with aviation connectors which enable MOTEC DC servo motors to be able to work in very harsh natural environment.

Absolute encoder(17bits) is available for MOTEC DC servo motors and the 17bits encoder can memorize position of a motor  when it lose its power supply (up to 2¹⁵). There is a battery in the encoder cable and it needs to be replaced periodically.

For more information about COBRA intelligent servo drive and motor please refer to COBRA intelligent servo system catalogue or send an inquiry to whan@vip.sina.com
