Home > Products > Aluminium Win-door machine > FRP Profile 4 Axis CNC Milling Drilling Machine
FRP Profile 4 Axis CNC Milling Drilling Machine
- T/T Credit Card
You May Like
-
Aluminum Cutting and Milling Machines ,end Milling Machine
-
Aluminium Doors Window Manufacturing Machine,window Door Machinery
-
Best Manufacturer of Aluminum Window Door Machines
-
Aluminum Window Machines
-
Industrial Aluminum CNC Milling Drilling Machine
-
Aluminum Profile CNC Milling and Drilling Machine for Aluminum Window Doors/ 4 Axis Copy Router Machine Center
Product Details
| Brand Name | PARKER | Place of Origin | Shandong, China | |
| Type | Horizontal | Certification | ISO CE | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 Year | |
| Weight | 3000kg | Dimension(L*W*H) | 7300mmx550mmx300mm | |
| Voltage | 380V/50Hz | Condition | New | |
| Power(W) | 10KW |
Product Description
Aluminum CNC Machining center
The machine is suitable for processing installation holes, water slot, shaped holes, and end milling and making screw on curtain walls and aluminum windows and doors
Feature
1.The Machine is suitable for processing installation holes ,water slot,shaped holes and end milling and making screw on curtain walls and aluminum windows and doors.
2.It adopts high-speed electric principal axis,which is imported from Italy.It’s extremely efficent and can swing in +-90 Angle
3.It adopts high-quality computer control system which is used in industry area specially,with good user interface,graphical programming and processing tracking interface,truly realize what you see and what you get.
4.It adopts high-quality servo motor,ball screw,linear guide pair and bearing and so on to ensure the machine runs with high precision.
5.Equipped six cutters positions,the cutter can change quickly and automatically.
6.The semi-closed guard improved security greatly
7.Clamping device position can be optimized and put to right position automatically and freely.
Parameter
Name 4 axis CNC machining center
Model DMCC6
Power 380V/50Hz/10kw
Air pressure 0.5-0.8Mpa
X axis stroke 7600mm
X axis speed 90000mm/min
Y axis stroke 960mm
Y axis speed 80000mm/min
Z axis stroke 610mm
Z axis speed 75000mm/min
Cutter Station 6 cutter,automatic change by program
Cutter Max.Length 165mm
Resetting error ±0.02mm
Processing error ±0.1mm
Surface roughness Ra12.5μm
Overall dimension:10100mmx2300mmx2600mm
Processing dimension :7300mmX550mmx300mm
Aluminum profile CNC Machining center video link
Parker Machinery Co.,ltd
/watch?v=hYwmgxfRge4
DMCC3H Axis Aluminum Profile CNC machining center
/watch?v=d5NHjVsZ-C4
4 axis machining center DMCC6
/watch?v=gjHc4hsMFQA
DMCC82 4 AXIS milling and drilling machine
/watch?v=tHN0X175AHQ
CPA3 Three Axis CNC Machining Center
/watch?v=kzr9v6RhlpI
DMCC3 3 Axis CNC Machining center
/watch?v=lEbIDLdHnok&index=20
DMCC3S 3 Axis milling and drilling machine for Aluminum
/watch?v=EOR14SR7NVk&index=21
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Products Name with link
91.8% Response Rate
Products Name with link
91.8% Response Rate
Products Name with link
91.8% Response Rate
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
