Aluminum CNC Machining center for milling drilling tapping
- 20 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
-
Aluminum Profiles CNC Double-Head Cutting Saw Double Mitre Saw Aluminum Cutting Cut Off Saw
-
Aluminum profile 4 Axis CNC Milling Drilling machine for Raiway
-
Cnc High Quality Machine Center For Aluminum Product Milling Drilling
-
Parker Aluminum Double head mitre saw with CNC
-
Aluminum CNC Cutting Saw Machine From Parker
-
Aluminum CNC Double head cutting machine
Product Details
| Brand Name | PARKER | Place of Origin | Shandong, China | |
| Model Number | DMCC6 | Type | Horizontal | |
| Certification | CE ISO | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | One Year | Weight | 3000kg | |
| Dimension(L*W*H) | 7300mmx550mmx300mm | Voltage | 380V/50Hz | |
| Condition | New | Power(W) | 10KW |
Product Description
Aluminum CNC Machining center
The machine is suitable for processing installation holes, water slot, shaped holes, and end milling and making screw on curtain walls and aluminum windows and doors
Feature of Aluminum CNC Machining center
Parameter of Aluminum CNC Machining center
Name 4 axis CNC machining center
Model DMCC6
Power 380V/50Hz/10kw
Air pressure 0.5-0.8Mpa
X axis stroke 7600mm
X axis speed 90000mm/min
Y axis stroke 960mm
Y axis speed 80000mm/min
Z axis stroke 610mm
Z axis speed 75000mm/min
Cutter Station 6 cutter,automatic change by program
Cutter Max.Length 165mm
Resetting error ±0.02mm
Processing error ±0.1mm
Surface roughness Ra12.5μm
Overall dimension:10100mmx2300mmx2600mm
Processing dimension :7300mmX550mmx300mm
Aluminum profile CNC Machining center video link
Parker Machinery Co.,ltd
/watch?v=hYwmgxfRge4
DMCC3H Axis Aluminum Profile CNC machining center
/watch?v=d5NHjVsZ-C4
4 axis machining center DMCC6
/watch?v=gjHc4hsMFQA
DMCC82 4 AXIS milling and drilling machine
/watch?v=tHN0X175AHQ
CPA3 Three Axis CNC Machining Center
/watch?v=kzr9v6RhlpI
DMCC3 3 Axis CNC Machining center
/watch?v=lEbIDLdHnok&index=20
DMCC3S 3 Axis milling and drilling machine for Aluminum
/watch?v=EOR14SR7NVk&index=21
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
