Aluminum Door Crimping for Sale Aluminium Window Machine
- T/T Credit Card
You May Like
-
Corner Crimping Aluminium Doors Window Manufacturing Machine
-
Aluminum Frame Crimping Aluminium Door and Window Making Machine
-
Easy Operation Aluminum Door and Window Punching Machine
-
Sliding Door Hydro-pneumatic Machine for Punch Aluminum Window
-
Different Dies Manual Hole Punching Machine for Punch Aluminum Window and Door
-
Aluminum Window Fabrication Machine CNC Rolling Bending Machine
Product Details
| Brand Name | FEIDA |
Product Description
Product Application aluminium window machine
--Applying to corner crimping of aluminum window profiles.
--Automatic positioning, clamping and crimping with high efficiency.
--Equipped with manifold cutters and clamps, suitable for varied profiles.
--Hydro-pneumatic boosting system, power deedless, energy-saving, low fault rate, low noise and good performing
reliability.
--Crimping strength adjustable anytime in accordance with difference of profiles, witch ensures profiles against getting
out of shape.
Main Specification aluminium window machine
1) Clamping strength: 2 x 5 t – 2 x 10 t
2) Pressure of oiling system: 0 – 40 MPa
3) Crimping height: 0 – 120 mm
4) Crimping head in up-and-down range: 0 – 60 mm
5) Max. travel of crimping head: 0 – 30 mm
6) Adjusting range of supporting cylinder: 0 – 40 mm
7) Supporting cylinder’s travel: 0 – 35 mm
8) Pneumatic working pressure: 0.5 – 1.0 MPa
9) Air consumption: 0.2 cubic m/min.
10) Dimensions: 74 x 800 x 1000 mm
11) Weight: 300 kg
Crimping Precision aluminium window machine
1) Crimped corner seam: ≤0.2 mm
2) Tolerance of height: ≤0.1 mm
3) Tolerance of angle: ± 5’
| Size | 1050(L) × 1200 (W) × 900(H) |
| Weight | 300 KGS |
| Packing details | Aluminum foil vacuumed /aluminium window machine |
