Mini Passive FTTH WDM (CATV+PON) Fiber Optical Receiver Node for Digital TV

FOB Price

USD $1 - $19 / Piece

100 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port Shanghai
Payment TermsT/T Credit Card PayPal Other

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DAYTAI		Place of Origin	China
Model Number	DT-PORW-FF

Product Description

Description

Passive FTTH WDM (CATV+PON) Optical Receiver (SC-F Female) for Digital TV,input Optical Power:-10 ~ +2dBm, Optical Return Loss:>45db,Optical Receiver Wavelength:1550±10nm,Optical Fiber Type:Single Mode, Frequency Range:40-1000MHZ,SC/APC to F Male connector,Dimensions:36*13 mm,Net weight:0.02KG.
Features

⊙No Power Required

⊙Optical Interface for data

⊙Designed for triple play FTTH

⊙PVC Casing(Color can be customized)

⊙Much smaller size and very easy install

⊙Frequency range 40-1000MHz For CATV Network

⊙ RF Interface for CATV End-Users (M-Male or F-Female )

⊙Built-in WDM, suitable for single-fiber triple wavelength system,

⊙RFTV operating wavelength 1550nm, pass wavelength 1310/1490nm,

can conveniently connect the ONU of GEPON, GPON.

Item	Unit	Description	Remark
Customer Interface
RF Connector	75Ω "M-Male & F-Female" connector
Optical Connector		SC/APC	Can be Customized
Input Optical Power	dBm	-10 ~ +2	Digital TV
Optical Return Loss	dB	>45
Operating Wavelength	nm	1550±10
Responsivity	A/W	≥0.9	1310_~1490nm
Optical Fiber Type		Single Mode
Frequency Range	MHz	40-1000
Flatness	dB	±1dB
RF Output Level	dBuV	≤62	-1dBm input power
Output Return Loss	dB	≥15
Output Impedance	Ω	75
C/N	dBc	＞50	-1dBm input power
Power Input Voltage	VDC	0
Power Consumption	W	N/A
Dimensions	mm	36*13
Net weight	KG	0.02

Hangzhou DAYTAI Network Technologies Co.,Ltd

Hangzhou DAYTAI Network Technologies Co.,Ltd is a high-tech enterprise specializing in research development, production in GEPON products,fiber optic communication (FTTH),Digital TV,Cable TV ,Ethernet Networking. Our company was established in 2013 in Hangzhou City,Zhejiang Province,China. We devote to making research and delveloping the newest equipements in the Telecommunication Industry. Constantly screen the Chinese fiber optic and CATV equipment market in a search of the most efficient product solutions available to satisfy your needs. Our major markets includes Chinese mainland , United States, Canada, Korea, France, Germany, Britain, Turkey, Ukraine, Italy, Australia, India, the Philippines, South Africa ,Indonesia,Mexico, Brazil and other countries.

FAQ

Q1: What's the lead time?
Re: Generally about 15-20 days after order confirmed, it depends one the order quantity.

Q2: Can you send sample?
Re: Yes, but the shipping cost will be paid by you, please contact us for more details.

Q3: What's your payment terms?
Re: 30% in advance, 70% before shipping.

Q4: What's the payment method?
Re: T/T, Western Union, Paypal, etc.

Q5: How to ship products?
Re: DHL, UPS, Fedex, TNT, EMS, air transport, ocean shipping.
