Passive 1 Way FTTH Fiber Optical Receiver Node for CATV Digital TV

FOB Price

USD $1 - $19 / Piece

100 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port Shanghai
Payment TermsT/T Credit Card PayPal Other

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DAYTAI		Place of Origin	China
Model Number	DT-POR-PFF/PFWF

Product Description

Description

Passive 1 Way FTTH Optical Converter patch cord type for Digital TV,input Optical Power:0~-18dbm,Optical Return Loss:>45db,Optical Receiver Wavelength:1100~1600 nm,Optical Fiber Type:Single Mode,Frequency Range:40-1000MHZ,SC/APC to F Female connector,Dimensions:36*13mm,Net weight:0.016KG.

Features

⊙No Power Required

⊙Good Linearity and Flatness

⊙Much smaller size and very easy install

⊙PVC Casing (Black & Green Color for optional)

⊙Designed For FTTH (Fiber To The Home Network)

⊙Frequency range 40-1000MHz For CATV End-users

⊙Optical Connector: SC/APC (Patch Cord type package PD)

Number Item	Description	Remark
Customer Interface
RF Connector	75Ω”M” connector
Optical Connector	SC/APC	Can be Customized
Optical Parameter
Input Optical Power	0~-18 dBm	Digital TV
Optical Retum Loss	>45db
Optical Receiver Wavelength	1100~1600
Optical Fiber Type	Single Mode
RF Parameter
Frequency Range	40-1000 MHz
Flatness	±0.5db
Output Level	70dbuV	0dbm optical input power
Output Impedance	75Ω
C/N	52dbc	0dbm optical input power
Other Parameter
Power Input Voltage	0 VDC
Power Consumption	N/A Ma
Dimensions	36*13mm
Net weight	0.016KG

Hangzhou DAYTAI Network Technologies Co.,Ltd

Hangzhou DAYTAI Network Technologies Co.,Ltd is a high-tech enterprise specializing in research development, production in GEPON products,fiber optic communication (FTTH),Digital TV,Cable TV ,Ethernet Networking. Our company was established in 2013 in Hangzhou City,Zhejiang Province,China. We devote to making research and delveloping the newest equipements in the Telecommunication Industry. Constantly screen the Chinese fiber optic and CATV equipment market in a search of the most efficient product solutions available to satisfy your needs. Our major markets includes Chinese mainland , United States, Canada, Korea, France, Germany, Britain, Turkey, Ukraine, Italy, Australia, India, the Philippines, South Africa ,Indonesia,Mexico, Brazil and other countries.

FAQ

Q1: What's the lead time?
Re: Generally about 15-20 days after order confirmed, it depends one the order quantity.

Q2: Can you send sample?
Re: Yes, but the shipping cost will be paid by you, please contact us for more details.

Q3: What's your payment terms?
Re: 30% in advance, 70% before shipping.

Q4: What's the payment method?
Re: T/T, Western Union, Paypal, etc.

Q5: How to ship products?
Re: DHL, UPS, Fedex, TNT, EMS, air transport, ocean shipping.
