Opticum/Orton/Globo9500HD
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | forever | Place of Origin | China | |
| Model Number | Globo9500HD |
Product Description
- MPEG-Fully DVB-S / DVB-S2 (H.264) HD compliant
- 8000 channels (TV and Radio) programmable
- Multilingual menu text support
- Channel switching time less than 1 second
- Channel list editing
- Favorite channel list editing
- True-color On-Screen Display (OSD)
- Full Picture In Graphic (PIG) function
- Electronic Program Guide (EPG) for on screen channel information
- Subtitle supported
- Teletext supported by VBI insertion and software emulation
- Parental lock facility by channel and program event
- Program and Channel information transfer from receiver to receiver
- Exciting games embedded
- S/PDIF for digital audio or Dolby AC-3 bitstream output
- DiSEqC 1.0, 1.1, 1.2 and USALS
- HDMI HD Video/Audio Output
- Dual Decoding (PIP)
- Software update via LAN port
- USB 2.0 Host
- VFD Display for service information
- RTC (Real-Time-Clock)
- LAN 10/100 Mbps Ethernet (optional)
- Time Shift (optional, only for PVR Ready receivers)
- Video Recording (optional, only for PVR Ready receivers)
- Recording 2 channels the same time, watching 3rd channel (within 1 transponder) (optional, only for PVR Ready receivers)
- Recording one channel and TimeShifting another channel (optional, only for PVR Ready receivers)
- Recording one channel and PIP another channel within the same transponder (optional, only for PVR Ready receivers)
General Data:
- 2xCard Reader slot with Conax embedded
- 2xCommon Interface slot for CAM modules
- Ethernet supported
- USB 2.0 Host support
- HDMI supported
- Video resolution 1080i, 720p, 576p, 576i
- Software & Channel Database Transfer via USB
- Blind scan
- Multi-LNB Controlled by DiSEqC control Version 1.0, 1.1, 1.2 and USALS
- Teletext support
- Multi picture display
- Powerful channel control by favorites, lock, skip, move and delete
- Multi-language supported (OSD & Menu)
- Optical Output for Digital Audio
System Resources:
- Main Processor: 400 MIPPS based CPU
- Flash Memory: 8Mbytes [Optional Expand]
- DDR SDRAM: 1024+512Mbits [Optional Expand]
Tuner/Channel:
- 1tuner: Decoding
- Input Connector: F-Type, Connector, Female
- Loop Through: F-Type, Connector, Female
- Signal Level: -65 to -25 dBm
- LNB Power & Polarization:
-Vertical: +13V/+14V
-Horizontal: +18V/+19V
-Current: Max 500mA
-Overload Protection
- 22KHz Tone: Frequency: 22±1KHz
- DiSEqC Control: Amplitude: 0,6±0,2V, Version 1.0, 1.1, 1.2, USALS Available
- Demodulation: 8PSK/QPSK
- Input Symbol Rate: 2-45 Mbps, Convolution Code rate 1/2
- 2/3, 3/4, 5/6, 7/8 and Auto
MPEG TS A/V Decoding:
- Transport Stream: MPEG-2/H.264
- Input Data Rate: 120Mbit/s max
- Aspect Ratio: 4:3, 16:9, Letter Box
- Video Decoding: 1920x1080i
- Video Resolution: 720x576 (PAL), 720x480 (NTSC)
- Audio Decoding: MPEG-1 Layers 1/2, Dolby AC-3
- Audio Mode: Left / Right / Stereo
- Sampling Rate: 33KHz, 44,1KHz, 48KHz
A/V & Data Input/Output:
- TV-SCART: Video CVBS/RGB output, Audio L/R output
- VCR SCART: Video CVBS output, Audio L/R output, Video CVBS, RGB input, Audio L/R input
- RCA A/V: 1x YPbPr output, Video CVBS output, Audio 2x L/R output
- S/PDIF: Optical, Coaxial Digital Audio or Dolby AC-3 Bit Stream Output
- RS-232C: Transfer rate 115,2Kbps, 9 pin D-sub type
- USB: USB 2.0, Compatible w/independent power supply output
- HDMI: VER1.2 Type A
RF-Modulator (Optional):
- PLL type: CH21~69 for the Demodulation
- TV Standard: PAL BG/I/DK selectable
- RF Connector: 75 Ohms, Male/Female
- Frequency Range: UHF : 470~860MHz
Power Supply:
- Input Voltage: 100-250 VAC, 50/60Hz
- Type: SMPS
- Power Consumption: 30W Max.
- Protection: Separate Internal Fuse and Chassis Grounding. The input shall have lighting or electric shock protection
Physical Specification:
- Size[W*H*D]: 360mm x 266mm x 65mm
- Net Weight: 2,49 kg
Environment:
- Operation Temperature: 0°C~+45°C
- Storage Temperature: -10°C~+70°C
- Storage Humidity: 5~95°RH (Non Condensing)
