SD DVB-T+CA

SD DVB-T+CI+FTA(MPEG-4,H2.64)
SD DVB-T+Irdeto(3.0), (MPEG-4,H2.64)
SD DVB-T+FTA+2 Tuner+PVR(MPEG-4,H2.64)
SD DVB-C+FTA, (MPEG

Detailed Description:

 SD  MPEG-4/2(H2.64) Series:
SD DVB-T+FTA, (MPEG-4,H2.64)
SD DVB-T+CI+FTA(MPEG-4,H2.64)
SD DVB-T+Irdeto(3.0), (MPEG-4,H2.64)
SD DVB-T+FTA+2 Tuner+PVR(MPEG-4,H2.64)
SD DVB-C+FTA, (MPEG-4,H2.64)
SD DVB-C+Muk-mCA, (MPEG-4,H2.64)
SD DVB-S+FTA, (MPEG-4,H2.64)
SD DVB-S+Irdeto(3.0), (MPEG-4,H2.64)
SD DVB-S2/S+Irdeto(3.0), (MPEG-4,H2.64)
SD DVB-S2/S+Irdeto(3.0)+USB(PVR),HDMI port ,(MPEG-4,H2.64)

Features:
* Irdeto and Nagravision Conditional Access System
* Multi-Mode auto search satellite programs (AUTO/FTA/NIT/TP)
* Maximum storage of 3000 Channels, 2000 Transponders and 100 Satellites
* Teletext on OSD
* Subtitle in ENGLISH/CHINESE
* Weekly EPG
* DiSEqC 1.0 and DiSEqC 1.2 control compatible
* 4 users defined Favorite groups with user-friendly editing functions
* Multi channel editing functions (delete, move, lock, skip, modify, etc.)
* Multi audio languages
* Multi OSD languages including Dutch, English, Turky, Arabic, Chinese, German, Spanish, Polski
* Automatic PAL / NTSC Detection
* Adjustable image color, brightness and contrast
* Adjustalble transparency OSD
* Convenient Channel list and satellite list
* Parental lock function
* ZOOM in/out
* Channel recall
* Video still
* Mute

Tuner
Satellite IF Input: 9502150MHz
Input impedance: 75
Signal Level: -65dBm25dBm
Connector: F type, Female, loop Out
LNB Power supply: 13/18v/OFF, mAX400mA
Band switch: 22KHz Tone

Demodulation
Standard: DVB-S EN300 421
Waveform: QPSK
Symbol rate: 2-45 MS/s
Roll off factor: 0.35
Reed Solomon decoder: Rs (204,188,8)
Code rate: 1/2,2/3,3/4,5/6,7/8

Video decoder
Standard: CD ISO/IEC 138182,MPEG-2 MP@ML
Video aspect ratio: 4:3,16:9
Video system: PAL and NTSC
Output Level: 1Vp-p(75Ω)(RCA)
Output Terminal: TV Scart/VCR Scart/S-video/RF output

Audio decoder
Standard: ISO/IEC 11172-3
Audio decoder: MPEG-1 Layer I and II
Audio channel: Mono, Dual-channel, Stereo
Volume control: 32 levels adjustment(600Ω unbalance)
Sampling Rate: 32/44.1/48kHZ

Modulation
RF output: 21ch~69ch PLL
Audio output:2×RCA
Video output: 1×RCA
