Product Details
| Brand Name | SANYING | Place of Origin | China | |
| Model Number | CBB65 | Type | Polypropylene Film Capacitor | |
| Application | Air Conditioner | Rated Voltage | 250VAC ~ 630VAC | |
| Operating Temperature | -25 ~+85 | Package Type | Surface Mount | |
| Capacitance | 4-150uF |
Product Description
General specifications:
1. Configuration & Shell: Aluminum shell
2. Temperature: -25°C ~ +85°C
3. Capacitance Range: 4μF-150μF
4. Capacitance Tolerance: ±5 %(J)±10 %(K)
5. Dissipation Factor: Tanδ≤0.001(at 100 Hz)
6. Nominal Frequency: 50/60Hz
7. Factory Testing Voltage & Time: T-T: 2.0Un 10s;T-C: 2000VAC 10s
8. Insulation Resistance: T-T:≥3000MΩ.μF
T-C:≥2000MΩ.μF
9. Rated voltage: 250 ~ 630VAC
10. Dissipation Factor: tg§≤0.001(at 100Hz)
11. Endurance Voltage: Between the electodes : 2.0 Un 10S
Between the electodes and the sheel: 2000VAC
12. Safety Class: P1
13. Life Class: B,C
14. Series Connection Inductance: It can be interconnected as required.
