Product Details
| Brand Name | GCOM | Place of Origin | China | |
| Model Number | S5100-20PC |
Product Description
Certification:CE, FC, UL, CCC
10/100/1000 Base-T Power Over Ethernet Switch , S5100-10PC 10 Port POE Gifabit Switch
□ 8*10/100/1000BaseT with POE power supply
□ 2*ComboGE(100/1000M BaseX SFP or 100/1000M BaseT)
□ 16K Jumbo, 8K MAC, 4K VLAN, QinQ
□ 256 ACL with IP+MAC+Port+VLAN binding
□ Full-loaded power consumption< 30W(without POE supply)
□ WEB/SNMP/Telnet
□ POE supply satisfy 802.3af and 802.3at
□ Max power consumption supply of single port is 32W
□ Maximum POE power consumption is 150W
? □ 335mm(W)*220mm(D)*44mm(H)
Product Specifications:
?
?
| Item | S5100-10PC |
| Backplane capacity | 48Gbps |
| Interface switching capacity | 20Gbps |
| Forwarding capacity | 14.9Mpps |
| Memory and flash | 64MB SDRAM memory and 8MB flash |
| POE features | Satisfy 802.3af and 802.3at standard, max power consumption supply of single port is 32W |
| Power consumption | Full-loaded≤25W (without POE) |
| Idle≤18W | |
| Dimensions (width x depth x height)) | 335mm×44mm×220mm |
| Weight (Full-loaded) | 4.5KG |
| Environmental requirements |
Operating Temperature:-15°C～55°C Storage Temperature:-40°C～70°C |
Business Features:
?
