Lug type butterfly valve

Materials Range:

Body: Cast iron, ductile iron, stainless steel, aluminium bronze, carbon steel, etc.
Disc: Plated ductile rion, aluminum bronze, stainless steel, carbon steel, etc.

Stem: ductile iron, aluminum bronze, Stainless steel. All can be customized for the surface of the disc.
Seat: NBR/EPDM/PTFE/VITON
Actuator: level, worm gear, electric and pneumatic.

Type Available: wafer or lugged type.
Sizes Available: DN50mm to DN300mm (2” to 12”)
Pressure Range: PN (MPa): 1.0, 1.6, 2.0, 2.5
Materials Standard: others on request
Basic Design: ANSI/AWWA C504
Face to Face Dimension: BS5155 Short, ISO5752 (Series 13), DIN 3202 F16
Inspection & Testing: API 598,
Flanged End Dimension:  DIN PN10/16/25, ANSI B16.1, BS4504, ISO PN10/16,
JIS B2212/2213, BS 10 Table D, BS 10 Table E
Suitable Mediums: fresh water, sea water, gas, oils, acids, alkalis, etc
Suitable Temperature: -26-82℃ (NBR), -26-135℃ (EPDM)

HeBei HengTong Valve Co.,Ltd is a manufacturer and exporter in HANDAN of China,specialize in valve manufacture and casting parts,forging,stamping,Material can be D.I/ C.I/C.S/S.S/GGG50/GGG40 etc.

Valve Standard Including:GB/DIN/GOST/BS/ANSI/AMMW

1.Main export market

  Southeast Asian

  Mid East Africa

  Central/South
