Automatic Top Labeling Machine

Model No.: LT-400

Automatic Top Labeling Machine LT-400 is designed for High Production Top Labeling Ex: Carton, DDL, Notebook,Plastic bag or box.

FEATURES:

• Stepper Motor for fast and accurate labeling performane

• Height and angle are adjustable

• Controlled by Microprocessor, LED display

• Label Count Down feature/ Production Run Counter

• One Touch label set and potitioning

• Modular design for easy maintenance/ Quick and easy Changeover

• Encoder Technology Synchronizes Conveyor with Dispensing

• In Line Application or Independent Operation

• Optium Sensing System offer the most accurate position

• Sanitary Stainless Steel Frame

• Heavy Duty Construction

OPTIONS:

• Servo Motor：Labeling Speed at 40 Meter / Min

• Touch Screen Control System with Job Memory

• Stainless Cabinet Type

• Hot Stamping Coding Machine(PE-200 , PM-200)/ Ink jet printer

• Passive Top Pressing Belt：For Slim Product (Suggested)

• Friction Flat Carton Feeder

• LION LDR2100 Clear Label Sensor

SPECIFICATIONS:

• Stepper Motor Driven

• Labeling Speed：40~150 pcs/ min

• Accuray：± 1mm

• Label Length：10~250 mm

• Label Width：10~100mm

• Label Roll：Inner diemeter 75mm Outer diemeter 300mm

• Power：Single Phase 110/220VAC, 50/60Hz

• Machine Dimensions：(L)1459mm (W)796mm (H)1400mm

AutoPack Co., Ltd.

Filling/Capping/Coding/Labeling/Tablet Counting/Turnkey System/Automation
E-mail: sales@autopacker.com
TEL: +884-3-3689806
Fax: +884-3-3689807
Address: No.15, Ln. 316, Guangxing Rd., Bade Dist, Taoyuan City 334, Taiwan (R.O.C.)
