ONU 20km 10G EPON Transceiver SFP+ Optical Module For I-temp SC Connector
- T/T L/C D/P D/A
- 7 days
You May Like
-
PR30 10G EPON Transceiver Complies With FDA 21 CFR 1040.10 And 1040.11 Class I
-
ONU BIDI SFF Receptacle GPON Module 2.5Gb/s , EPON Transceiver
-
Telecom Industrial CWDM Optical Fiber Transceiver Complies With SFP MSA
-
EN 60825-1 / A1 10Gbs OTN CWDM Optical Transceiver 40km / XFP Modules
-
300m 850nm SFP+ Transceiver Module for 10GBASE-SR / SW , Fiber Optic Transceiver
-
FDA 21 CFR 1040.10 and 1040.11 class 1XFP Transciver For OTN Built - in CDR
Product Details
| Brand Name | Superxon | Place of Origin | China | |
| Model Number | SOEX3667-PSIGA |
Product Description
Certification:TUV/FCC/UL/ROHS/FDA/CDRH
EPON ONU 20km / SFP+ Optical Transceiver for I-temp
Specifications:
|
P/N |
SOEX3667-PSIGA |
|
Data?rate: |
10Gbs |
|
Distance |
20km |
|
Wavelength |
1310nm?T/1577nm?R |
|
Transmitter |
DFB |
|
Receiver |
APD |
|
DDM |
Yes |
|
Connector |
SC |
|
Operating?Temperature |
-40~85℃ |
|
Voltage?Supply |
3.3V |
|
Brand |
Superxon |
|
Certification |
TUV/FCC/UL/ROHS/?FDA/CDRH |
Features:
??Single?fiber?bi-directional?data?links?Asymmetric?TX?1.25Gbps/RX10.3125Gbps?application
??-40°C?to?85°C?operating?case?temperature
??Single?3.3V?power?supply
??SFP+?package?with?SC/UPC?Receptacle?connector
??Digital?diagnostic?monitor?interface
??Hot-pluggable?capability
??High?power?1310nm?DFB?LD?and?high?sensitivity?APD
??Support?20km?transmission?distance?with?SMF
??CML?compatible?data?input/output?interface
??Low?power?dissipation
??Low?EMI?and?excellent?ESD?protection
??RoHS-6?compliance
APPLICATIONS :
?????Asymmetric?10GEPON?PRX30?ONU?with?15~29dB?attenuation?range
STANDARDS:??Complies?with?SFP+?MSA?(SFF-8431)
Complies?with?IEEE?802.3av Complies?with?SFF-8472 Complies?with?FCC?47?CFR?Part?15,?Class?B Complies?with?FDA?21?CFR?1040.10?and?1040.11,?Class?I Competitive?Advantage: 1?Excellent?quality?with?2?years?warranty 2?Keep?stock?,?Fast?delivery 3?Competitive?pricing 4?Full?compatible 5 OEM/ODM?Customized?labelContact Us
