Home > Products > CWDM Optical Transceiver > 10km CWDM Optical Transceiver LC Receptacle 10.3Gb/s , Fiber Channel Transceiver
10km CWDM Optical Transceiver LC Receptacle 10.3Gb/s , Fiber Channel Transceiver
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
CDR CWDM Duplex SFP+ Optical Transceiver With Digital Diagnostic Monitoring
-
1270nm - 1610nm CWDM Optical Network Transceiver LC Receptacle 10.3Gbs
-
Superxon 9.3Gbs XFP Optical Transceiver 40 km For DWDM Networks
-
EML CWDM Optical Transceiver Support 9.95Gb/s To 11.1Gb/s Bit Rates
-
CWDM SFP+ Duplex Optical Transceiver FDA / CDRH / FCC / UL / TUV / ROHS
-
10km 10.3Gb / s CWDM Optical Transceiver 2 Years Warranty / QSFP+ Modules
Product Details
| Brand Name | Superxon | Place of Origin | China | |
| Model Number | SO01CW77-PLGA-xx |
Product Description
Certification:FCC/UL/FDA/CDRH/TUV/ROHS
CWDM Duplex SFP+ Optical Transceiver
Specifications:
|
P/N |
SO01CW77-PLGA-xx |
|
Data rate: |
10.3Gbs |
|
Distance |
10km |
|
Wavelength |
1270nm-1610nm |
|
Transmitter |
DFB |
|
Receiver |
PIN |
|
DDM |
Yes |
|
Connector |
LC |
|
Operating Temperature |
0~70℃ |
|
Voltage Supply |
3.3V |
|
Brand |
Superxon |
|
Certification |
TUV/FCC/UL/ROHS/ FDA/CDRH |
Features:
Up to 13dB Power Budget
Low power dissipation
SFI electrical interface????
Class I laser safety standard IEC-60825 compliant
RoHS-6 compliance
Low EMI and excellent ESD protection
Built- in Digital Diagnostic Monitoring (DDM) function
Supports 9.95Gb/s to 11.3Gb/s bit rates
0 to 70°C operating case temperature
SFP+ package with duplex LC receptacle connector
Hot-pluggable capability
Single 3.3V power supply
CWDM DFB transmitter and high performance PIN-TIA receiver
Application:
10GBASE-LR/LW
CWDM Network
10Gb/s Fiber Channel
Standards
Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Complies with SFP+ MSA (SFF-8431)
Complies with SFF-8472
Compliant with IEEE 802.3ae
Complies with FCC 47 CFR Part 15, Class B
Competitive Advantage:
1 OEM/ODM?Customized label
2?Keep stock , Fast delivery
3?Excellent quality with 2 years warranty
4 Manufacturer, factory price
