Dual - CDR Multi - Rate XFP Transceiver 40km 1550nm / Fiber Optic Modules
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Performance SFP+ Optical Transceiver For 10GBASE-LR / LW CPRI
-
CPRI 1.2288Gbps BIDI Optical Transciver With Digital Diagnostic Monitoring
-
DFB 10km BIDI Optical Transceiver Complies With FCC 47 CFR Part 15 Class B
-
1310nm T / 1550nm R BIDI Optical Transceiver 40km / LC , SFP Fiber Optic
-
APD 1.25Gbs BIDI Fiber Optic Module 40km Complies With SFP MSA
-
Compact BIDI Optical Transceiver 10km Full Compatible / SFP Optical Module
Product Details
| Brand Name | Superxon | Place of Origin | China | |
| Model Number | SO045599-XLGA |
Product Description
Certification:TUV/FCC/UL/ROHS/FDA/CDRH
Optic Fiber Equipment XFP Transceiver 40km / 1550nm
?
Optical Characteristics:
?
Parameter | Symbol | Minimum | Typical | Maxim | Unit | Note |
Transmitter |
||||||
Average Launch Optical Power | POUT | -1 | - | 2 | dBm | |
Extinction Ratio | ER | 8.2 | - | - | dB | |
Centre Wavelength | λ | 1530 | 1565 | nm | ||
Spectral Width (-20dB) | Δλ | - | - | 0.5 | nm | |
Side Mode Suppression Mode | SMSR | 30 | dB | |||
Tx Jitter (SONET) 20kHz-80MHz | Txj1 | 0.3 | UI | |||
Tx Jitter (SONET) 4MHz-80MHz | Txj2 | 0.1 | UI | |||
Transmitter Dispersion Penalty | TDP | 2 | dB | |||
Mask margin | 10 | % | ||||
Input Differential Impedance | ZIN | 90 | 100 | 110 | Ω | |
Data Input Swing Differential | VIN | 120 | - | 820 | mV | |
Transmit Disable Voltage | VD | 2 | Vcc | V | ||
Transmit Enable Voltage | VEN | GND | GND+0.8 | V |
||
Transmit Disable Assert Time | 10 | us | ||||
Receiver |
||||||
Optical Center Wavelength | λC | 1270 | - | 1600 | nm | |
Receiver Sensitivity | -16 | dBm | ||||
Receiver Overload | -1 | dBm |
||||
Receiver reflectance | -27 | dBm | ||||
LOS De-Assert | -20 | dBm |
||||
LOS Assert | -30 | 6 | dBm | |||
LOS Hysteresis | 0.5 | 5 | dB |
“INF-8077i, Revision 4.5”
“IEEE Std 802.3aeTM-2002”
“Dual-CDR Multi-Rate Transceiver with EML Driver” GN2010E Datasheet,
“Smallest TEC Power Drivers for Optical Modules” Data Sheet,
“ITU-T G.691”
?
Competitive Advantage:
?
1. Excellent quality with 2 years warranty
2. Competitive pricing
3. OEM/ODM?Customized label
4? Keep stock , Fast delivery
