Home > Products > GPON Transceiver > Full Compatible ONU BIDI SFF Optical Transceiver 1.25Gb/s TX / 2.5Gb/s RX
Full Compatible ONU BIDI SFF Optical Transceiver 1.25Gb/s TX / 2.5Gb/s RX
- T/T L/C D/P D/A
- 7 days
You May Like
-
2.488Gb/s 40km CWDM Fiber Optics Module Complies With FCC 47 CFR Part 15 Class B
-
Gigabit - Capable Passive Optical Networks GPON Transceiver Complies With SFF MSA
-
1310nm TX / 1490nm RX GPON Transceiver CLASS B+ Reach , SFP Module
-
CPRI SMF CWDM Optical Transceiver 2.5Gb / s 20km LC - Connector
-
SFP Module With MAC Optical Transceiver 2.5Gb/s EPON For I - Temp OEM ODM
-
3.3V CWDM Optical Transceiver FOR Digital Repeater And Base Station
Product Details
| Brand Name | Superxon | Place of Origin | China | |
| Model Number | SOGP3412-FAGA/B |
Product Description
Certification:TUV/ FCC/ UL/ROHS/FDA
Specifications:
|
P/N |
SOGP3412-FAGA/B |
|
Data?rate: |
2.5Gb/s |
|
Distance |
CLASS B+ |
|
Wavelength |
1310nm?T/1490nm?R |
|
Transmitter |
DFB |
|
Receiver |
APD |
|
DDM |
Yes |
|
Connector |
SC/APC |
|
Operating?Temperature |
-0~70℃ |
|
Voltage?Supply |
3.3V |
|
Brand |
Superxon |
|
Certification |
TUV/FCC/UL/ROHS/?FDA/CDRH |
FEATURES
Single fiber bi-directional data links with asymmetric 1244Mbps upstream and 2488Mbps downstream
1310nm DFB burst mode transmitter
1490nm APD-TIA continuous mode receiver
High power 1550nm video signal rejection
0 to 70°C operating case temperature for C-temp class, and -40 to 85°C operating case temperature for I-temp class,
2×10 SFF package with SC/APC or SC/UPC pigtail connector
Single 3.3V power supply
LVPECL logic level data input interface
CML logic level data output interface
LVTTL burst enable control
LVTTL receiver signal-detected indication
TX_SD function
Digital diagnostic monitor interface compatible with SFF-8472
Low EMI and excellent ESD protection
Class I laser safety standard IEC-60825 compliant
RoHS-6 compliance
APPLICATIONS
Gigabit-capable Passive Optical Networks(GPON) ONT with video-overlay
STANDARDS
Complies with SFF MSA(1998 version form-factor)
Complies with ITU-T G.984.2, G.984.2 Amendment 1, G.984.2 Amendment 2
Complies with ITU-T G.984.5
Complies with SFF 8472
Complies with FCC 47 CFR Part 15, Class B
Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Competitive Advantage:
1. Excellent quality with 2 years warranty
2 Competitive pricing
3.OEM/ODM?Customized label
4 Keep stock , Fast delivery
