Home > Products > Die-Casting LED Display > P5.21 3 In 1 RGB Slim Led Display Boards Indoor For Disco , Bar

P5.21 3 In 1 RGB Slim Led Display Boards Indoor For Disco , Bar

FOB Price

USD $ $1 - $ $1 / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	LS-5

Product Description

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1. Brilliant contrast ratio, high resolution/high definition

2. Super light and can be installed by one person

3. Super uniformity and no mosaic

4. Available Product Models: P3.91, P4.46, P5.21, P6.25.

5.?Waterproof Level: IP21

6.?Brightness(cd/m2)>2000nit

P5.21?3?In?1?RGB?Slim?Led?Display?Boards?Indoor?For?Disco?,?Bar

Description:

1. Supper thin Design?

500 x 500 x 83mm per panel.

2. Fast ?and simple Assembly

No tools needed, one person can install at least 70 cabinets per hour. One person can finish the whole

process alone.

3. Light Weight?

One Cabinet only weights 8 KG, 32KG for one square meter.?

4. Aluminum Materials?

good appearance, anti-corrosiveness . 8 kg/panel,

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;

Specifications:

1. Indoor LED Display Technical Parameter? ? ?

Model No.	LS5
Pixel Pitch	5.21mm
Module Size	250*250mm
Module Resolution(pixels)	48*48
Panel Size	500mm×500mm
Panel Resolution(pixels)	96×96
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	36864
Brightness(cd/m2)	2000
Best Viewing Distance(m)	6-100
Max.Power Consumption(W/m2)	1350
Waterproof Level	IP21
Wavelength	R 620-625 G 520-525 B 470-475
LED SPEC	2020
Viewing Angle	140°(H)/60°(V)
Operating Temperature	–20~50°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50000 hours
Lifespan	≥100000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/10
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure

2. Indoor LED Display Module? ?

Dimensions (w x h)	250mmx250mm	Resolution (w x h)	48 x 48
Pixel pitch	5.21mm
