Single Side P12mm Front Service LED Display Screen For Road Side

Model No.

NS-OR-DD-P12

Pixel Pitch

12mm

Module Size

192 mm ×192mm

Module Resolution(Pixel)

16 dots×16dots

Pixel Density

6944 dots/m2

LED Type

3mm Oval Lamp

Pixel Configuration

1R1G1B

Wavelength (R.G.B)

R:625±2nm G:525±2nm B:470±2nm

Drive Mode

Dynamic 1/4 Duty Constant Current

Cabinet Size

1152×768×150mm

Cabinet Resolution

96dots×64dots

Brightness

≥6000 cd/m2

Contrast

≥2000:1

Viewing Angle

110°(Horizontal )/45°(Vertical )

Best Viewing Distance

10~300 m

Grey Scale

10bits/1024levels

Color Capability

16777216

Color Temperature

5000-9300K

Maximum Power Consumption

1000 W/m2

Average Power Consumption

350W/m2

Working Voltage

AC220V/110V s±15% 50-60 HZ

Frame Frequency

≥60HZ

Refresh Frequency

≥240HZ

Brightness Correction

Pixel, Module, Cabinet Correction

Operating Temperature

Static:-40°C ~ +85°C Working:-20°C ~ +60°C

Operating Humidity

10-90% RH

LED Lifespan

100,000 hours

MTBF

≥50000 hours

Computer Operation System

Win 98/ Win XP/ Win 2000

Video Signal Input

RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite

Video Signal Output

RF, S-Video, GB, RGBHV, YUV, YC etc.

Graphics Card
