Home > Products > Stage Background LED Screen > P10 RGB SMD3535 Stage LED Display Curtain For Celebration Event

P10 RGB SMD3535 Stage LED Display Curtain For Celebration Event

FOB Price

USD $ $1 - $ $1 / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	NS-IR-DS-P6

Product Description

Delivery Time:20-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1. High brightness: >6000cd/㎡

2. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness

3. Waterproof Level: IP65(Front Side), IP54 (Back Side)

4. CE,CCC,RoHS,UL,ISO9001

5.?Cabinet connection angle can be adjusted by -15 degree to +15 degree

6.??Long lifespan> 100,000 hours
?

P10?RGB?SMD3535?Stage?LED?Display?Curtain?for?Celebration?Event

Description:

1. High brightness & Waterproof?

Brightness reaches 6000nits, IP65. It is perfect to be used for both indoor and outdoor.

2. Light Weigh & Ultra Thin

Made by high quality aluminum material, one cabinet only weights 8.5 KG. It makes installation job and

delivery more comfortable and convenient. 95 mm thickness saves not only space for delivery but also

installation.

3. Angle Adjustment?

Cabinet connection angle can be adjusted by -15 degree to +15 degree.?This allows you shape arc

shapes.

4. Fast Lock System & No Fan Design

Easy to install and dismantle: an average worker can finish 70 panels per hour. Natural cool system design

and good heat dissipation.

Applications:

Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts

Specifications:

1. WS10 Technical Parameter??

Model No.	WS10
Pixel Pitch	10.417mm
Module Size	500mm*83.33mm
Module Resolution (W*H)	48 dots*8 dots
Pixel Density	9216 dots/ ㎡
LED Type	SMD 3535
Pixel Configuration	1R1G1B
Wavelength (R.G.B)	R:625±2nm G:525±2nm B:470±2nm
Drive Mode	Dynamic 1/4 Duty Constant Current
Cabinet Size	500×500×95mm
Cabinet Resolution	48dots×48dots
Brightness	≥6000cd/㎡
Contrast	≥2000:1
Viewing Angle	140°(Horizontal )/140°(Vertical )
Best Viewing Distance	7m-300m
Grey Scale	10bits/1024levels
Color Capability	16777216
Color Temperature	5000-9300K
Maximum Power Consumption	1500 W/m2
Average Power Consumption	700 W/m2
Working Voltage	AC 220V/110V s±15% 50-60 HZ
Frame Frequency	60-85 HZ
Refresh Frequency	240 - 1000HZ
Brightness Correction	Pixel, Module, Cabinet Correction
Operating Temperature	-40~+65℃
Operating Humidity	10-90% RH
LED Lifespan	100,000 hours
MTBF	≥50,000 hours
Computer Operation System	Win 98/ Win XP/ Win 2000
