Home > Products > Omni Fiberglass Antenna > WLAN WIMAX Repeater / Base Station Omni Fiberglass 5.8GHz Antenna 5725 - 5850 MHz 12 dBi
WLAN WIMAX Repeater / Base Station Omni Fiberglass 5.8GHz Antenna 5725 - 5850 MHz 12 dBi
- T/T L/C D/P D/A
- 7 days
You May Like
-
Outdoor Omni Fiberglass 433MHz Wireless Point To Multipoint Antenna 6 dBi 20 * 1200
-
Vertical Multiband Log-periodic Hi-Gain Wireless Antenna With N Female Connector
-
Point to point Outdoor Yagi Wireless Antenna High Gain Directional 18DBI
-
2.4GHZ ISM High Gain Wireless Antennas / 2400 MHz - 2483 MHz Flat Panel Antenna
-
accurate position Car GPS Antenna Tracking Sensitive High 3m Black
-
RIFID Wireless High Gain Antenna / 2.5dBi Rubber Duck Antenna indoor
Product Details
| Brand Name | Runshine | Place of Origin | China | |
| Model Number | RSF-5800-12 |
Product Description
Certification:ROSH
?WLAN WIMAX? Repeater / Base Station Omni Fiberglass 5.8GHz Antenna 5725 - 5850 MHz 12 dBi
Application:
● 5.8GHz UNII / ISM frequency
● 5.8GHz WLAN WIMAX system
● Point to Multipoint applications?
● Repeater & Base station system
● Signal coverage
Feature:
● Good appearance
● Durable, corrosion resistance
● Full day for working ,waterproof
● Optimized dimension
● High Gain, Lower VSWR,Strongly Anti-interference? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ??
Specification
|
Model?NO |
RSF-5800-12 |
|
Electric?Spec |
|
|
Frequency?rang-MHz |
5725-5850 |
|
Bandwidth?-MHz |
125 |
|
Gain?-dBi |
12 |
|
beam?width?-° |
H:360???V:7 |
|
VSWR |
≤1.5 |
|
Input?Impedance-Ω |
50 |
|
Polarization |
Vertical |
|
Max?power?-W |
100 |
|
Lightning?protection |
DC?ground |
|
Connector?model |
N?Female |
|
Mechanical?Specification |
|
|
Size?-mm |
Φ20*650 |
|
Antenna?weight-kg |
0.46 |
|
Working?Temperature?-°c |
-40～60 |
|
Rated?Wind?Velocity-m/s |
60 |
|
Radome?color |
gray |
|
Mounting?way |
hold?in?the?pole |
Antenna details :
Application Example :
Install demonstration
View of us ;
