USB HDD mobile video recording / automotive dvr recorder RS485 , RS232 interface

Brand Name	Fortune Mount International Ltd.		Place of Origin	China
Model Number	MCH4GNN

Delivery Time:1-4 weeks after get the full payment
Certification:CE, FCC

Hi3520D Escort Vehicles Mobile DVR Recorder Embedded LINUX Local Playback HDD Network Storage?
?

Advantages:

variety of video mode, meet the needs of different customers Wide voltage design, suitable for all kinds of vehicles Hard disk smoked pull box, compatible with all 2.5 -inch hard disk market Anti-shock design hard disk, hard disk protection performance better To support the large capacity hard disk, maximum 4 TB

Product Features:

Playback quality:support 4ch D1,4ch 960H,8ch D1 real-time recording Main and Sub Stream:Main stream for local storage, ensure image quality;Sub-stream for real-time network transmission, easy to solve bandwidth bottleneck problem. Mobite monitor: Support various mobile monitoring(iPhone,Windows Mobile,BlackBerry,Symbian,Android) Display:support TV output,taking the lead in HD resolution technology. Operation interface:similar to Windows operating style, easy to get started with powerful mouse right-click function. Network: Powerful network services (support DAS,DHCP,PPPOE,FTP,DNS,DDNS,NTP,UPNP,EMAIL, IP permissions, IP searches, Alarm Center, etc.) and perfect support (WEB, Client, SDK), easy to achieve interoperability. Browsers: Support multiple web browsers (ie,chrome,firefox, safari) Remote Access: With its own domain name service functions (ARSP), and one key to remote monitoring,monitoring becomes easy and enjoyable. 3322 (Greek network), dyndns, oray (peanut shells), myq-see and other Domain Name Services are also provided.

SPECIFICATIONS

system	Main processor	Hi3520D
Operating system	Embedded LINUX operating system
System resources	Simultaneous multi-channel real-time recording, playback, network operation, USB backup
interface	user interface	support 16-bit true color graphical menu interface and mouse operation
preview screen	1/4
video	vdieo standards	PAL(625line,50f/s)；NTSC(525line,60f/s)
vdieo compression	H.264(Main Profile)
display quality	Monitor:D1
play quality	960H/D1/Half-D1/CIF/QCIF
encode capacity	4ch 960H real-time
decode capacity	1ch 960H real-time
motion detect	Zones: 392(22*18)detection zones per window,multi-level sensitivity
audio	audio compression	G.711A
bidrectional talk	supported
Record & playback	record mode	manual>alarm>motion detection>timing
local playback	Any channel playback simultaneously(1-4ch)
search mode	Time/calendar/event/channel search
Storage & backup	space occupation	video:CIF 4~5G/ day*channel, D1 8~10G/ day*channel； ?audio:691.2M/ day*channel
record storage	HDD,network
backup mode	Network backup,USB HDD,U disk
interface	video input	4ch
video output	1ch RCA (1.0Vp-p,75Ω),1ch for cable
audio input	4ch
audio output	1ch (200-3000mV,5K)
alarm input	4ch(multiplexing vehicle signal)
alarm output	2ch
RJ45 interface	no
RS485, RS232	One RS485,one RS232
