Realtime 4CH High definition digital video recorder , analog hd dvr for survillance

Brand Name	Fortune Mount International Ltd.		Place of Origin	China
Model Number	AHR-AP104

Delivery Time:1-4 weeks after get the full payment
Certification:CE, FCC

?4CH Hard Disk Storage AHD DVR H.264 High-definition Video Display Security DVR?

Quick Detail:

Low power consumption, low-carbon environmental protection Adopt the H. 264 high compression technology, compression rate is higher, the quality is better? G.711?Audio Coding HDD Port?support a?SATA port max 4TB More than 20 kinds of languages to break the national boundaries P2P/NAT Function: Plug and Play fuction (No setting for DDNS and port forwarding when IE browser remote view)? Display Resolution: 720P, Record Resolution: 720P??Hard disk info: Support One SATA HDD, PTZ: RS485, USB port: Two High speed USB2.0? Remote View: Support IE browser and client software, Support for mouse operation, come with 1pc mouse.? Support Mobilephone Surveillance?

?Features:

?H.264 Video Standard and G.711 Audio standard Support 720P HD preview,recording and playback;?analog video transmission technology, coaxial cable as the transmission medium;Coaxial two-way data Cable send control signals such as head rotation, zoom control, etc Transmission over long distances, 720P via 75-3 coaxial, ensures transmission of 500-meter HD video signals Anti-interference ability,under strong interference environment ensure the transmission of high-definition video display, distortion does not occur, dropped frames Apply a new UI, more intuitive and simple user experience using the menu style 3 full display Video features: manual recording, timer recording, motion detection etc; USB interface backup and network backup - support CVBS, VGA and HDMI output simultaneously,VGA, HDMI Full 1080P, to overturn traditional monitor display?

SPECIFICATIONS

Performance Parameters
Sensor	Main Board Sensor	Industrial Embedded Microprocessor
Operating System	Embedded LINUX operating system
System	Video Coding	H.264
Coding Resolution	4CH 720P(1280x720)
Video Frame	PAL:1~25FP/S;NTSC:1~30FP/S
Video Bit Rate	512Kbps-4096Kbps,Customizable,Default to be 2048Kbps
Stream Type	Video Streaming / Composite Stream
Double Stream	Support
Audio Coding	G.711
Audio Sampling rate	8KHz,16Bit
Audio Bit Rate	64Kbps
Video Spec	Video Input	4CH BNC Port
Video output	1CH CVBS,1CH VGA output,1CH HDMI port
Recording Manage	Recording Mode	Automatic recording, Manual Recording, Motion Detection Recording, Alarm Recording
Playback	4CH Playback
Backup Mode	Mobile Hard Disk / U-Hard-Disk / Network
Network	Protocol	Support TCP/IPUDPRTP/RTSPDHCPPPPoEDDNSNTP etc.
IE Control	With WEB Server to modify configuration parameters and remote control IE
P2P Cloud	Support login via to meet One-Key Remote Control.
Mobile Remote	Support IOS, Android,Blackberry, Symbion, Software .
HDD	HDD Port	Support 1SATA port max 4TB,No e-SATA port.
Interface	Network/USB	1?RJ45 port, 100M E-internet Port ; 2PCS USB Port
Interface	1PC Standard RJ485 port
Others	Power/Consumption	DC12V? ; less than15W(No HDD)
Temperature/Humidity	Temperature:-10deg-+55deg/? Humidity: 10%~90%
