Product Details

Brand Name	Fortune Mount International Ltd.		Place of Origin	China
Model Number	MCS1NNN

Product Description

Delivery Time:1-4 weeks after get the full payment
Certification:CE, FCC

H.264 ?4 Channel Video Input Mobile DVR Recorder With SD Card Storage Motion Detect

Product Features:

Special function:GPSdata,wide voltage,mobile DVR player,SDK etc. Compression algorithm ideal: H.264 High Profile compression algorithm,30% decrease of stream due to advanced space-time filtering technology Playback quality:support 4ch D1 real-time recording,2ch Dl real-time playback. Main Stream:Main stream for local storage, ensure image quality Display: support TV output Operation interface:similar to Windows operating style Differentiation: Boot screen free replacement, more than twenty languages, over 10 sets of GUI interface, ten kinds of remote control, available in dozens of button panel, which make our products different from others. Others:Perfect circuit protection, unique triple watchdog function, ensure that the equipment never crashes；With unique black box technology, the whole process can be monitored, which greatly reduces maintenance costs. 4 channel Video Input support 1*SD Card Storage;( SD maximum 64G)

SPECIFICATIONS

	Model	MCS1NNN
system	Main processor	Industrial Embedded Microcontrollers
Operating system	Embedded LINUX
System resources	Simultaneous multi-channel real-time recording, playback, network operation, USB backup
interface	user interface	support 16-bit true color graphical menu interface and mouse operation
preview screen	1/4
video	vdieo standards	PAL(625line,50f/s)；NTSC(525line,60f/s)
vdieo compression	H.264(High Profile)
display quality	monitor:D1
play quality	D1/Half-D1/CIF/QCIF
encode capacity	4ch D1 real-time(default CIF)
decode capacity	2ch D1 real-time
motion detect	Zones: 392(22*18)detection zones per window,multi-level sensitivity
audio	audio compression	G.711A
bidrectional talk	supported
Record & playback	record mode	manual>alarm>motion detection>timing
local playback	Any channel playback simultaneously(1-4ch)
search mode	Time/calendar/event/channel search
Storage & backup	space occupation	video:CIF 4~5G/ daychannel, D1 8~10G/ daychannel； ?audio:691.2M/ day*channel
record storage	SD
backup mode	Network backup,USB,USB Burn
interface	video input	4ch
video output	1ch RCA (1.0Vp-p,75Ω),1ch cable
audio input	4ch
audio output	1ch(200-3000mV,5K)
alarm input	no
alarm output	no
net interface	no
PTZ control	One RS485,one RS232
usb	One USB
Mobile interface & functions	GPIO	Support? OSD overlay, storage(optional) etc
GPS	Not Support
	others
