Product Details
| Brand Name | JL | Place of Origin | China | |
| Model Number | MZ-1000D |
Product Description
Certification:ISO9001,CE
MZ-1000D IGBT Inverter Submerged ARC Welding machine
Features:
IGBT MODULE INVERTER
ARC FORCE
ABS PHASE PROTECTION
AMP AND VOLT DIGITAL DISPLAY
MULTI FUNCTION: MMA,SUBMERGED ARC WELDING, GOUGING
Option:
1 Separate auto welding cart MZ-3C and connecting cable
Description:
IGBT module inverter technologies Welding voltage and current display Stable welding arc and high performance welding Heavy duty cycle Welding voltage and current preset function Multi functions: SAW, MMA, Gouging With separate auto welding cart and long cable Suitable for shipyard and other industry use| Item | MZ-630D | MZ-1000D | MZ-1250D |
| Input voltage(V) | 3*380/400/415/440 | 3*380/400/415/440 | 3*380/400/415/440 |
| Frequency(HZ) | 50/60HZ | 50/60HZ | 50/60HZ |
| Input power capacity(KVA) | 35 | 50 | 60 |
| No-load voltage(V) | 75-85 | 75-85 | 75-85 |
| Rated output voltage(V) | 44V | 44V | 44V |
| Current range(A) | 100-630 | 100-1000 | 100-1250 |
| Rated duty cycle(%) | 60(40℃) | 60(40℃) | 60(40℃) |
| Diameter of wire(MM) | 2.0/2.5/3.0 | 2.5/3.0/4.0/5.0 | 3.0/4.0/5.0/6.0 |
| Weight(KGS) | 68 | 120 | 135 |
Parameter for Welding cart MZ-3C
| Model | MZ-3C |
| Wire speed | 20-200mm/min |
| Welding speed | 15-150mm/min |
| Welding head regulate range(vertical) | 95mm |
| Welding head regulate range(horizontal) | ±35mm |
| Stand column up/down range | 100mm |
| Welding head right-lift angle | 45° |
| Welding head front-rear angle | 60° |
| Dimensions(LXWXH) | 920*455*820 |
| Weight(KG) | 52 |
