22kw Steel Deck Roll Forming Machine with Galvanized Board / 30 Groups Rollers
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
18.5kw Easy Operation Deck Roll Forming Machine For Galvanized Steel Sheet
-
5.5kw Motor Corrugated Roll Forming Machine With Automatic Control System For Steel Plants
-
Compressive Strength , Flatness Z Purlin Roll Forming Machinery with 15 Rows Rollers
-
60Hz 3 Phase Double Layer Roll Forming Machine for Roof Panels
-
5.5kw Hydraulic Station Power Steel Sheet Forming Machine for IBR Roof in One Line
-
380V Double Layer Roll Forming Machine with Alternating Current Frequency Conversion
Product Details
| Brand Name | DB | Place of Origin | China | |
| Model Number | According to requirements |
Product Description
Certification:ISO,CE,SGS
22kw Ridge Cap / Steel Deck Roll Forming Machine with Galvanized Board / 30 Groups Rollers
Introduction and Guarantee :
1. This machine contains our experiences in 30 years and many times improvements by our engineers.
2. In our service, we support the equipments and profiles that customers really need and including our most sincere recommends.
3. Our roll forming machines are driven by chain in hydraulic system. Chain Drive System can save the power compare with other system. That also means that customers do not need to pay the extra power fee during production of steel panel.
Applications:
|
Construction |
Food?Services |
Lawn?&?Garden |
Shelving |
|
Automotive |
Fencing |
Lighting |
Store?Fixture |
|
Display?Industry |
Furniture |
Material?Handling |
Sporting?Goods |
|
Farming |
HVAC |
Mining |
Transportation.etc |
Specifications:
|
Suitable?to?process |
colored?steel?plate,galvanized?board |
|
Width?of?the?plate |
1200mm |
|
Rollers |
30?groups |
|
Rolling?material |
Forging?steel?45# |
|
Rolling?galvanization?thickness |
0.7-1.5mm |
|
Material?of?the?cutting?blade |
Cr12mov |
|
Dimensions |
Approx20m*1.6m*2m |
|
Power |
22kw |
|
Thickness?of?the?plate |
0.7-1.5mm |
|
productivity |
10m-15m/min |
|
Diameter?of?the?roller |
85mm |
|
Weight |
About?8T |
|
Voltage |
380V?50Hz |
|
Processing?precision |
Within?1.00mm |
|
Equipment?components |
Man-made?uncoiler,roll?forming?machine, Compture?control?system Hydraulic?control?system Press?foming?cutting |
|
Transportation |
One?complete?equipment?need?one?40?feet?container?to?hold |
Advantage:
1. We use Automatic control software to manage productive information.
2. Thanks to the High integrated network, the whole automatic control system has an improvement in automaticity.
3. High performance in operation, maintenance, and debugging. Easy to load and unload.
4. First in quality??????
5. First in time
6. First in price
7. First in services
The profile drawing:
Working flow:
Photo of main roll forming machine:
Output table and manual decoiler:
Sample:
Factory scene:
Product certificates:
