Copper Strip Slab Continuous Casting Machine Horizontal With Melting And Holding Furnace
- T/T L/C D/P D/A
- 7 days
You May Like
-
Bronze Plate Strip Continue Casting Machine Double Strand Horizontal
-
3 Strand Horizontal Continuous Casting Machine , Brass Strip Casting Machine
-
Alloy Copper Plate Strip Horizontal Continuous Casting Machine Two Strand
-
Alloy Cu - Ni Copper Continuous Casting Machine One Strand 20mm Thickness
-
Horizontal Copper Continuous Casting Machine , Tin Phosphors Bronze Strip Billet CCM
-
Automatic Horizontal Continuous Casting Machine 2 Strand For Alloy Copper Plate Strip
Product Details
| Brand Name | Jingjie | Place of Origin | China | |
| Model Number | 2 strands copper strip CCM |
Product Description
Copper Strip Slab Continuous Casting Machine Horizontal With Melting And Holding Furnace ?
?
Ⅰ. SPECIFICATIONS
1. Types of casting specifications
* Oxgen free copper
?
1.1 ?Plate-strip billets (rectangular-shaped)
Thickness range * width range (8--20)*(420--650) mm
Range of coil's internal diameter Φ(500--800)mm
Max. outer diameter of coils Φ1600 mm
Max. coil weight 8000 KG
Number of production lines 1--3 lines(To be decided according to section conditions)
?
?
?
Ⅱ.PROCESS
?
? ?
Ⅲ.MAJOR TECHNICAL PARAMETERS OF EQUIPMENT?
| 1.1 | Casting speed: | |
| ? | Traction speed | 0-64 mm/s (Stepless adjustable) |
| ? | Backstepping speed | 0-64 mm/s (Stepless adjustable) |
| ? | Strip optimum line speed | 90-120mm/min |
| ? | ? | ? |
| 1.2 | Equipment power: | |
| ? |
Combination furnace: Smelting Holding |
500Kw 200Kw |
| ? | Traction machine | 7.5Kw |
| ? | Hydraulic shear stress | 80T |
| 1.3 | Shear thickness | 20mm(max) |
| 1.4 | Coiling machine parameters | ? |
| ? | Coiling weight |
6000Kg |
| ? | Inside Diameter of Coil |
Φ500-800mm |
| ? | Coil diameter | 1600mm |
| 1.5 | Machine noise value | Less than 85 dB |
| 1.6 | Height of machine operation line | +1000mm |
| 1.7 | Machine drive direction | Right drive |
| 1.8 | Production capacity | ? |
| ? | 2 Strands: 750-1200Kg/h | width: 470mm thickness: 25mm |
| ? | Equipment assembly machine power | 700Kw |
Ⅳ. ?MAIN PROCESS PARAMETERS ?
| 1 | Output | 750-1200Kg/h |
| 2 | Temperature regulating range | ≤1300℃ |
| 3 | Temperature control precision of thermal insulation furnace | ±5℃ |
| 4 | Vertical and horizontal tolerance |
Horizontal: + 0.10mm Vertical:±0.20mm |
| 5 | Push and pull adjustment range |
Push:0-64mm/s ±0.1mm(electrodeless) Pull:0-64mm/s ±0.1mm(electrodeless) |
| 6 | Sickle curve | 1.5mm/m |
| 7 | Dragger adjustment range |
Drag:0-64mm/s ±0.1mm(electrodeless) Backsteppingl:0-64mm/s ±0.1mm(electrodeless) |
| 8 | Drag maximum line speed | 120mm/min |
| 9 | Coiling adjustment range |
Inside Diameter of coil Φ500-Φ800mm External diameter of coil Φ1600mm |
| 10 | Maximum coiling speed |
250mm/min |
| 11 | Elastic adjustment range | 0.95-0.75 |
| 12 | Tower dgree of coiliing | ≤40m |
| 13 | Unit power consumption | 430kWh/t |
?
Ⅴ. EQUIPMENT PARTS LIST?
