High Speed 12 - 15 m/min Storage Shelf, Steel Rack Roll Forming Machine For Rack Beam
Negotiable
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
First Grade 45# Steel Storage Rack Roll Forming Machine With 1.8 - 2.3mm Thickness
-
18 Groups Forming Roller Stand Upright Rack Roll Forming Machine for Storage Rack
-
Q235 Cold Rolled Strip / Hot - Dip Galvanizing Steel Cable Tray Roll Forming Machine
-
12 - 15 m/min Forming Speed Steel Rack / Cable Tray Forming Machine
-
2.0mm Thickness Cable Ladder Profile Roll Forming Machine With 16 Steps Forming Station
-
Hot - Dip Galvanizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine TW-CBT300
Product Details
| Brand Name | TECHWELL | Place of Origin | China | |
| Model Number | TW-RACK |
Product Description
High Speed 12 - 15 m/min Storage Shelf, Steel Rack Roll Forming Machine For Rack Beam
Main Specification
Material Thickness:1.8-2.3mm
Total Power: 22.5KW
Dimension of Storage Rack Roll Forming Machine: about 13500mmx1200mmx1300mm
Weight of machine: about 13 Ton
Roll Diameter: 75mm
Forming Roller stand: 18 Groups
Main Axis material: First grade 45# steel, heated and quenched
Roller material: GCr15 Steel, Quenched and heated process
Forming Speed: 12-15 m/min
Working Flow
Decoiler ---- Servo Feeding --- Punching--- Levelling--- Roll Forming ---- Cutting ---- Run out table
