Q235 2.0mm Thickness Cable Tray Profile Roll Forming Machine For Rack Beam
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
16 Forming Steps Cable Tray Profile / Cable Ladder Forming Machine With Hydraulic Punching TW-CBT300
-
YX-86-194-312 W Beam Guardrail Roll Forming Machine For 2 - 4mm Material Thickness
-
Galvanized Steel Sheet 2 Wave Guardrail Curving Machine for Curvinging Highway Guardrail Profile
-
7 Rollers Leveling 10 - 12m/min W Beam Roll Forming Machine for Crash Barrier
-
15 Forming Station Crash Barrier Roll Forming Machine for Highway Guardrail TW-W312
-
Forming Speed 10 - 12m/min W Beam Guardrail Forming Machine for Crash Barrier TW-W312
Product Details
| Place of Origin | China | |
| Model Number | TW-CBT300 |
Product Description
Q235 2.0mm Thickness Cable Tray Profile Roll Forming Machine For Rack Beam
Main Specification
Suitable Plate Material: Galvanized steel and black steel sheets, thickness:1.2mm, Width from 100mm-600mm, height 50-100mm
Working Speed: 10meters / min
Forming stations: about 20 stations
Material of Roller: Gcr15, Quench HRC58-62 Plated Chrome
Material of Shaft: 45# Advanced Steel (Diameter: *90mm), thermal refining
Driven system: Chain Driven 1.5 inches 20A
Main Power with reducer: 15KW WH Chinese Famous
Cutting: Hydraulic Cutting Cr12mov
Material of Cutting Knife: Cr12Mov, Quench HRC58-62
Hydraulic Station Power: 7.5KW Wuxi Wanshen Famous Chinese Brand
The whole machine is controlled by industry computer-PLC.
PLC--Mitsubishi, Japan
Touch Screen—Panasonic, Japan
Encoder--Omron, Japan
Working Flow
Auoto Decoiler – Tranporting & 9 Rollers Leveling – Servo Feeding -- 100 Ton Punching machine -- Oriented – Transportation – 8 Holes Punching -- Main Forming -- Cutting -- Run out table
Application
Cable tray, cable ladder, cable profile, tray profile
