ST - SC Patch Cable Fiber Optic Patch Leads 3.0mm Violet Color OFNR Outer Jacket
- T/T L/C D/P D/A
- 7 days
You May Like
-
MTRJ MU Lc To Fc Adapter Black Plastic Housing For FTTH Newwork
-
High Reliability / Stability Hybrid Fiber Optic Adapter , Female To Male Adapter
-
ST Multimode Fiber Optic Connector Adapters Simplex And Duplex With Bronze Sleeve
-
MPO UPC Singlemode Fiber Optic Adapter for Fiber Optic Patch Panel
-
ST Duplex Optical Fiber Adapter OM3 Aqua Plastic Housing For Telecommunication
-
Flangeless Fiber Optic Adapter with Shutter for Optical Passive Device
Product Details
| Brand Name | TTI | Place of Origin | China | |
| Model Number | ST-SC |
Product Description
Certification:ISO, SGS, ROHS
ST - SC Fiber Optic Patch Cable 3.0mm Violet Color OFNR Outer Jacket
?
?
Description:
?
Optical patch cord is a length of optical fiber with two ends adding connectors to connect beam path.
?
TTI patch cords assembled with various types of connectors (such as FC, SC, ST, LC, MU, MTRJ,MPO etc.)
?
There are three kinds of polishing ferrule end-face: PC, UPC and APC .We employ advanced technique and equipment to manufacture so as to ensure the high quality of mass production.
?
Features:
?
High return loss
Low insertion loss
Patch cord Passed RoHS,ISO9001
LZSH or PVC jacket
CCTC A Type optical fiber Ferrule?
Fiber Connector Options: FC/SC/LC/ST/MU/E2000/MT-RJ/MPO/MTP
Polishing Options: PC/UPC/APC
?
Application:
?
LAN, CATV
Building cabling
Pigtails and patch cords
Network
Broadband
?
Specification:
Multimode fiber optic patch cord? |
|||
Fiber type | OM1(62.5/125μm) ; OM2(50/125μm) ; OM3(50/125μm-150; 50/125μm-300) |
||
Operating Wavelength | 850 nm |
||
Jacket material | PVC/LSZH/OFNP |
||
Diameter of fiber? | 0.9/2.0/3.0mm |
||
Contector? | SC LC or customized |
||
polishing method | PC | UPC | APC |
Insertion ?loss (IL) | ≤0.2dB | ≤0.2 | ≤0.3 |
Return ? loss (RL) | ≥45dB | ≥50dB | ?≥60dB |
Repetitiveness | ≤0.1dB? |
||
Exchangeability | ≤0.2 |
||
Durability | >1000 times? |
||
Operating?Temperature(oC) | -40~85 |
||
Storage?Temperature(oC) | -40~85 |
||
length | customized |
||
?
Order Information:
?
?
Fiber?Optic?Patch?Cord |
|||||
Connector? Type | Ceramic?Ferrule | Cable?Diameter (mm) | Simplex/Duplex | Single?mode | Length (M) |
| FC | PC/UPC/APC | Φ0.9,?Φ2,Φ3 | Simplex/Duplex | SM/MM | Customized |
| SC | PC/UPC/APC | Φ0.9,?Φ2,Φ3 | Simplex/Duplex | SM/MM | Customized |
ST | PC/UPC | Φ0.9,?Φ2,Φ3 | Simplex/Duplex | SM/MM | Customized |
LC | PC/UPC | Φ0.9,?Φ2 | Simplex/Duplex | SM/MM | Customized |
MU | PC/UPC | Φ0.9,?Φ2 | Simplex/Duplex | SM/MM | Customized |
MTRJ | PC/UPC | Φ0.9,?Φ2 | Duplex | SM/MM | Customized |
Product Picture:
?
