High Speed FTP Cat 7 Network Cable 4 Pair 22AWG Green 305 m/roll

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	WONTERM		Place of Origin	China
Model Number	WT7803-SF

Delivery Time:10 working days after received your payment
Certification:CE/FCC/UL/ROHS

High Speed FTP Cat 7 Network Cable 4 Pair 22AWG Green 305m/roll

Specifications:

Conductor	Solid bare copper
AWG	23
Conductor Diameter (mm)	0.583 ±0.02
Insulation	Foam - skin PE
Insulation average hickness	0.419mm(Min at any point0.369mm)
Jacket	PVC/LSZH
Sheath average thickness	0.05mm (Min. at any point:0.40mm)
Sheath Diameter	7.4 ± 0.3mm
Elongation	Min.100%
Tensile strength	Min. 1.407kg/m2
Aging at 100 for 168Hrs	Min. elongation retention: 50%
?	Min. tensile strength retention: 75%

Standard compliance:

1.?All Proposed Category 7 requirements as per ANSI/TIA/

EIA, ISO/IEC, and CENELEC EN Standards.

2. ANSI/TIA/EIA 568-B.2-10, draft

3. ISO/IEC 11801 CLASS F, 2nd Edition

4. CENELEC EN 50173-1

5. CENELEC EN 50288-4-1,2nd Edition

6. CENELEC EN 50288-4-2

7. Flame Retardancy is verified according to IEC 60332-1-2.

Electrical Performance

Applications:

Competitive Advantage:

1.?OEM are welcome. We can also produce standard or non-standard wires and cables.

2.?Premium custom service: Fast response within 24hours for any requirements.

3.?Our products adopt green technology design.
