Casting Steel Impulse High Pressure Steam Trap PN25 , A182F22
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | HONGFENG920 | Place of Origin | China | |
| Model Number | HR150A, HR260A |
Product Description
Casting Steel Impulse High Pressure Steam Trap PN25 ,?A182F22
?
Quick Details:
?
?
Preesure: 0.03 - 1.6 Mpa
Material: A105 or WCB
Temperature: 425 ℃
Working Media: Steam, Condensate Water
Air Insulation
? Specifications
Steam Trap
Reliable Operation With Air Insulation
Built-in Strainer
High Temperature & Pressure
Installed in Any Direction
Design Pressure: PN540
Preesure: 1.6 - 26 Mpa
Material: Forged Steel A182 F22
Temperature: 550 ℃
Working Media: Steam, Condensate Water
End Connection: Flange, Screw & Socket Welded
Thermodynamic Steam Trap / Disc Type Steam Trap / Thermo Dynamic Steam Trap
HR150A, HR260A
1. Reliable operation for its air insulation that can not be influenced by surrounding. 2. Hard quenching stainless steel and accurate grinding surface is resistant to abrasion and twist under high temperature condition and ensure long service life. 3. Built-in strainer with large surface area can prevent impurity, which ensures no failure operation. Can be installed in any directions.?
HR150
1. Steam jacket insulation is not influenced by surrounding and prevents no load cycling effectively. 2. Built-in strainer with large surface area can prevent impurity, which ensures no failure operation. Hard quenching stainless steel and accurate grinding surface is resistant to abrasion and twist under high temperature condition and ensure long service life. 3. Can be installed in any directions.?
Application:
Steam traps are suitable for saturated steam and over heated steam pipe with high temperature and pressure especially extra high pressure.
