Casting Steel WCB Ball Float Steam Trap

Quick Details:

Design Pressure: PN25

Preesure: 0.01 - 1.6 Mpa

Material: Casting Steel WCB

Temperature: 425 ℃

Working Media: Steam, Condensate Water??

Ball Float Steam Trap
Discharge Continuously
Small Size Large Capacity
Built-in Air Vent & Strainer
High Back Pressure Rate

Ball Float Steam Trap / Float Steam Trap / Mechanical Steam Trap

G10:

1: Float drives the rod to adjust the opening of drain valve seat ostiole. Working continuously. The trap can discharge amounts of condensate continuously with small physical size.
2: Good performance of sealing, low leakage rate and efficient in energy conservation.
3: Built-in automatic air venting unit with good performance of discharging non-condensable gas can prevent air locking and start quickly.
4: Back pressure rate up to 80%, which easy to recover condensate.
5: Horizatal and vertical installation.
?

Application:
this lever float steam trap is suitable for steam pipe net and steam heating equipment to block steam and discharge condensate.
?

Introduction to lever Float Steam Traps:
Valve in the steam trap can be opened and closed by utilizing lever and amplification device. In the valve float connects lever, which drive valve core. The float can adjust opening of trap automatically. Built-in automatic air vent can prevent air locking and rapid start-up is provided. There is no steam leak for the water seal in valve.
