Casting Steel Ball Float Steam Trap Valves Automatic 0.01 - 2.0 MPa

Casting Steel Ball Float Steam Trap Valves Automatic 0.01 - 2.0 MPa

Quick Details:

Double Ported Balance Valve System
Built-in Air Vent & Strainer

Design Pressure: PN40

Preesure: 0.01 - 2.0 Mpa

Specifications

Ball Float Steam Trap
Double Ported Balance Valve System
Built-in Air Vent & Strainer
Stainless Steel Internals
Horizontal Installation

Design Pressure: PN40

Float Steam Trap / Ball Float Steam Trap / Mechanical Steam Trap

GSB6.5:

1: Float drives the rod to adjust the opening of drain valve seat ostiole. Working continuously. The trap can discharge amounts of condensate continuously with small physical size.??
2: Good performance of sealing, low leakage rate and efficient in energy saving.
3: Built-in automatic air venting unit with good performance of discharging non-condensable gas can prevent air locking and start quickly.
4: Back pressure rate is up to 80%, which easy to recover condensate.
5: Horizatal and vertical installation.

Application:

This ball float steam trap is suitable for steam pipe net and steam heating equipment to block steam and discharge condensate.

Introduction to lever Float Steam Traps:
Valve in the steam traps can be opened and closed by utilizing lever and amplification device. In the valve float connects lever, which drive valve core. The float can adjust opening of trap automatically. Built-in automatic air vent can prevent air locking and rapid start-up is provided. There is no steam leak for the water seal in valve.
