Outdoor RG11 Tri - Shield Coaxial Cable 14 AWG PVC Jacket Low Loss
USD $4 - $5
/ Case
1 Case(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Jelly PE RG11 Quad - Shield CATV Coaxial Cable 60% and 40% AL Braid for Direct Burial
-
75 Ohm CATV Coaxial Cable RG11 Quad - Shield with Messenger Coaxial Cable CCS Conductor
-
AL Braiding RG11 CATV Coaxial Cable / Antennas Quad Shielded Coax Cable
-
CCS Conductor RG11 Coaxial Cable Quad - Shield AL Braiding CMR Rated PVC
-
75 Ohm RG11 Quad Shield Coaxial Cable 60% and 40% AL Braiding with Messenger
-
RoHS Standard PVC Jacket CATV RG11 Coax Cable 14 AWG CCS 60% AL Braid With Messenger
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Outdoor RG11 Tri - Shield Coaxial Cable 14 AWG PVC Jacket Low Loss
Quick Detail:
RG11 Tri-Shield?Coaxial Cable 14 AWG CCS Conductor 60% AL Braiding Foamed PE Insulation CM Rated PVC 75 Ohms? Tested to 3GHz ISO, CE, RoHS, UL 100M, 305M, Wooden Spool, CartonDescription:
KT2072 RG11 Tri-Shield Coaxial Cable?14 AWG CCS 60% AL Braiding CM Rated PVC
?is a specific type of CATV Coaxial Cable , RG11 (Produced by KINGTONE) is perfect for
digital Cable and Satalite, Attenas, and communication systems. RG11 has a characteristic
impedance of 75 ohms. KINGTONE using best raw material and best worker to produce
RG11 to meet high performance in practical application. RG11 is packed in 500FT/1000FT
plastic/wooden spool, and will be layed on pallet to protect the spool and easier carry.
Because of good managing methods, KINGTONE’S price of RG11 is not high although
our quality is really high.
Applications:
Suitable for RF signal transmission
■ CATV
■ MATV
■ CCTV
■ Local Area Network
■ Digital video
■ Antennas
| KT2072?RG11?Tri-Shield Coaxial Cable?14 AWG?CCS?+?60%?Braid?+?PVC?CM (UL)?1000ft | ||
| Construction?Parameters: | ||
| ??Inner?Conductor | 0.064\"/1.63mm/14AWG? | Copper?Clad?Steel |
| ??Dielectric | 0.280\"/7.11mm?????????? | Foamed?PE |
| ??Shield?1 | 0.287\"/7.29mm? | Bonded?Aluminum?Polyproylene |
| ??Shield?2 | 60%?coverage?? | Aluminum?braid?wire? |
| ??Shield?3 | (Non-bonded) | Aluminum?Laminated?Tape |
| ??Jacket | 0.400\"±0.006\"/10.16±0.15mm? | PVC |
| ??Jacket?Thickness | 0.039\"/0.99mm | |
| ??Application | For?Use?in?Longer?CATV?Run?Lengths | |
| ? | ||
| Electrical?Characteristics: | ||
| ??Inner?Conductor?Resistance | The?Max.?at?20℃?shall?be?<??87?Ω/km??<??26.53?Ω/1000ft | |
| ??Capacitance | 52?±3?pF/m????15.85?±1?pF/ft | |
| ??Impedance | 75?±?3?Ω | |
| ??Return?loss? | between?5?and?1000MHz:?>?22dB | |
| ??Velocity?of?Propagation? | 0.85 | |
| ??Sparker?Test?(VAC) | 4 | |
| ? | ? | ? |
| Attenuation(20℃): | ||
| Frequency?(MHZ)???????????? | Max?Attenuation(dB/100ft) | Max?Attenuation?(dB/100m) |
| 5 | 0.38? | 1.25? |
| 55 | 0.96? | 3.15? |
| 83 | 1.18? | 3.87? |
| 187 | 1.75? | 5.74? |
| 211 | 1.90? | 6.23? |
| 250 | 2.05? | 6.72? |
| 300 | 2.25? | 7.38? |
| 350 | 2.42? | 7.94? |
| 400 | 2.60? | 8.53? |
| 450 | 2.75? | 9.02? |
| 500 | 2.90? | 9.51? |
| 550 | 3.04? | 9.97? |
| 600 | 3.18? | 10.43? |
| 750 | 3.65? | 11.97? |
| 865 | 3.98? | 13.05? |
| 1000 | 4.35? | 14.27? |
| ? | ||
| Mechanical?and?Environmental?Properties | ||
| ??Cable?bend?radius | 10?times?the?cable?diameter | |
| ??Operating?Temp?Range??(PVC) | -20?℃?to?60?℃ | |
| ??Cable?diamensions | 0.40\'\'±0.006\'\'/10.21±0.15?mm??PVC? | |
| ? | ||
| Order?Informations: | ||
| ??Marking |
KINGTONE?KT2072?RG11?60%?Tri?Bonded?PVC?CM?CATV?COAXIAL?CABLE?××× M/FT |
|
| ??Package | 500FT/Pull?Box,?1000FT/Wooden?Spool,?Pallet | |
| ??Delivery?time | Normally?25?days?after?received?the?deposit. |
Competitive Advantage:
1, ?From raw materials to final products, we perform intense quality checks to maintain our product quality:
? ? ?A, Incoming material inspected by QC.
? ? ?B, Manufacturing Process Control
? ? ?C: Workers trained daily/weekly/monthly
? ? ?D:
