Home > Products > RG59 Coaxial Cable > RF Signal Transmission UL CMR RG59 Coaxial Cable 75 Ohm AL Braiding Cable
RF Signal Transmission UL CMR RG59 Coaxial Cable 75 Ohm AL Braiding Cable
USD $4 - $5
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Tri - Shield 20 AWG RG59 Coaxial Cable with Non-Plenum CM Rated PVC
-
Aluminum Braiding Tri - Shield RG59 Coaxial Cable for CATV CCTV
-
Semi Flexible Signal Coaxial Cable 0.29mm Silver Plated CCS with 1.68mm PTFE
-
Waterproof Signal Coaxial Cable 670 - 086 / 25 with Tin Soaked Copper Braiding
-
Outdoor Black Signal Coaxial Cable 50 Ohm 195 0.94mm Bare Copper
-
200 Tinned Copper Braided 50 Ohm Signal Coaxial Cable with PVC Jacket for GPS
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
RF Signal Transmission UL CMR RG59 Coaxial Cable 75 Ohm AL Braiding Cable?
Quick Detail:
RG59 Coaxial Cable 75 Ohm Coaxial Cable 20 AWG CCS Conductor? 95% AL Braiding Foamed PE Insulation UL CMR Rated PVC Tested to 3GHz ISO,CE,RoHS,UL 100M, 305M,?Wooden Spool, CartonDescription:
KT2017 RG59?Coaxial Cable 20 AWG CCS Conductor Foamed PE 95% AL Braid PVC CMR?
?is a specific type of CATV coaxial cable , RG59(Produced by KINGTONE) is perfect for
digital Cable and Satalite, Attenas, and communication systems. RG59 has a characteristic
impedance of 75 ohms. KINGTONE using best raw material and best worker to produce
RG59 to meet high performance in practical application. RG59 is packed in 500FT/1000FT
plastic/wooden spool, and will be layed on pallet to protect the spool and easier carry.
Because of good managing methods, KINGTONE’S price of RG59 is not high although
our quality is really high.
Applications:
Suitable for RF signal transmission
■ CATV
■ MATV
■ CCTV
■ Local Area Network
■ Digital video
■ Antennas
| KT2017?RG59 Coaxial Cable?20AWG?CCS?Foamed PE AL Foil?95%?Braid?PVC?CMR?or?CMG (UL) | ||
| Construction?Parameters: | ||
| ??Inner?Conductor | 0.032\"/0.81mm/20AWG? | Copper?Clad?Steel |
| ??Dielectric | 0.144\"/3.66mm??????????? | Foamed?PE? |
| ??Shield?1 | 0.151\"/3.84mm? | Bonded?Aluminum-Polyproylene |
| ??Shield?2 | 95%?coverage?? | Aluminum?braid?wire? |
| ??Jacket | 0.240\"±0.006\"/6.10±0.15mm?? | PVC?CMR?or?CMG(UL) |
| ??Jacket?Thickness | 0.032\"/0.81mm? | ? |
| ??Application | For?Use?in?Longer?CATV?Run?Lengths | |
| ? | ||
| Electrical?Characteristics: | ||
| ??Inner?Cond.?Resistance | The?Max.?at?20℃?shall?be?<??87?Ω/km??26.5?Ω/1000ft | |
| ??Capacitance | 52?±3?pF/m??15.8?±1?pF/ft | |
| ??Impedance | 75?±?3?Ω | |
| ??Return?loss? | between?5?and?1000MHz:?>?22dB | |
| ??Velocity?of?Propagation? | 0.85 | |
| ??Sparker?Test?(VAC) | 4 | |
| ? | ||
| Attenuation(20℃): | ||
| Frequency ????????????(MHZ)???????????? |
Max?Attenuation ?(dB/100ft) |
Max?Attenuation ??(dB/100m) |
| 5 | 0.86? | 2.82? |
| 55 | 2.05? | 6.73? |
| 83 | 2.45? | 8.04? |
| 187 | 3.60? | 11.81? |
| 211 | 3.80? | 12.47? |
| 250 | 4.10? | 13.45? |
| 300 | 4.45? | 14.60? |
| 350 | 4.80? | 15.75? |
| 400 | 5.10? | 16.73? |
| 450 | 5.40? | 17.72? |
| 500 | 5.70? | 18.70? |
| 550 | 5.95? | 19.52? |
| 600 | 6.20? | 20.34? |
| 750 | 6.97? | 22.87? |
| 865 | 7.52? | 24.67? |
| 1000 | 8.12? | 26.64? |
| ? | ||
| Mechanical?and?Environmental?Properties | ||
| ??Cable?bend?radius | 10?times?the?cable?diameter | |
| ??Operating?Temp?Range?? | -20?℃?to?60℃ | |
| ??Cable?diamensions | 0.242\'\'±0.006\'\'/?6.15±0.15?mm?PVC?CMR?or?CMG(UL) | |
| ? | ||
| Order?Informations: | ||
| ??Marking | KINGTONE?KT2017?RG59?95%?Bonded?PVC?CMR?CATV?COAXIAL?CABLE?×××M/FT | |
| ??Package | 500FT/Pull?Box,?1000FT/Wooden?Spool/Pallet | |
| ??Delivery?time | Normally?25?days?after?received?the?deposit. |
Competitive Advantage:
1, ?From raw materials to final products, we perform intense quality checks to maintain our product quality:
? ? ?A, Incoming material inspected by QC.
? ? ?B, Manufacturing Process Control
? ? ?C: Workers trained daily/weekly/monthly
? ? ?D: Work instructions manual at each work station
? ? ?E: 5S
