Sell Slitting Line

Place of Origin	China

Model No.:KJS-1200
Product Origin:China
Brand Name:King Jime
Price Terms:FOB Shenzhen
Payment Terms:L/C
Certification:
Description:Product Name: Slitting LineModel Number: KJS-1200Place of Origin: ChinaSpecifications: 1) Model: KJS-1,000/1,300/1,500/2,000 2) Coil thickness: 0.15-0.5/0.25-1.5/0.3-2/1-8mm 3) Coil width (mm): 1,000/1,300/1,500/2,000 4) Coil weight (kg): 2,000-3,000/5,000/10,000 5) Coil OD (mm): 1,200/1,500 6) Coil ID (mm): 508 7) Feed speed: 20m/min 8) Main motor (kW): 30/55/72 9) Coil expansion: hydraulic/mandrel 10) Uncoiler motor (kW): AC 0.75/1.5 11) Recoiler motor (kW) 55/72 Features: Slitting line can do uncoiling, slitting and recoiling works, for any width coil steel. It mainly includes coil car, uncoiler, shearer, correct device, slitting machine, scrap recoiler, tension unit, press unit, recoiler and coil car, and hydraulic system. It is mainly used in coil or hot rolling carbon steel, silicon steel and all the other kinds of metal materials with surface spreading. This line can be adjusted to do recoiling or dividing work to meet customers' demands. PLC system is used to select the information from every part of the line, centrally controlled. Speed self adjusted function keeps memory after power cut. So the line has efficient performance. Outer packing: Wooden cases
