Cold Drawn ST52 honed tube for hydraulic cylinder industry DIN2391 En10305
- T/T L/C D/P D/A
- 7 days
You May Like
-
Thin type small pneumatic cylinders Aluminum Alloy , Compact Air Cylinder
-
Single piston rod , double acting car hydraulic cylinder 8 - 16MPa Pressure class
-
1050 , 3003 , 5052 Grade Seamless Gas Cylinder Tubing Heat Extrusion , Welding
-
Aluminium alloy supercharge / Pressurized pneumatic air cylinder , compact pneumatic cylinders
-
20# , 45# , 16Mn Hydraulic Cylinder Tube / Pipe Honed Surface Treatment
-
Precision Linear Shaft , Long 45 # Carbon Steel Hollow Shaft For Shock Absorber
Product Details
| Brand Name | JLF | Place of Origin | China | |
Product Description
| Type: |
honed tube
|
Brand Name: |
HT
|
Place of Origin: |
Jiangsu China (Mainland)
|
| Packaging Detail: | Nude packed. Oiled and capped in both ends |
| Delivery Detail: | 25 days |
1 OD32-500mm W.T.3.5-80mm?
2 ISO certificated DIN2391 En10305?
3 Straightness:0.3~1mm/m?
4 Inside Roughness:0.4~0.8um
steel pipes for hydraulic use
Material: C20, CK45, etc. also ST52 if given enough time. our products are widely used in hydraulic industry and is very popular both home and abroad.
And we can also make our products according to the customers\' needs.
Variety
|
Processing |
Cylinder diameter |
Length /mm |
Straightness |
Size accuracy |
Wall thickness/mm |
Inner bore roughness |
|
Cold-drawn |
ID30~OD250 |
≤13M |
0.3~1.0mm/m |
?H9-H11 |
±8% |
0.8~1.6um |
|
Honed tube |
ID50~OD325 |
≤10M |
0.3~1.0mm/m |
H7-H9 |
±8% |
0.4~0.8um |
?Mechanics performance
|
Material |
Tensile strength |
Yield strength |
Elongation |
Hardness |
|
Ck20 |
510 σ N/mm2 |
500σsN/mm2 |
5δs% |
175HB |
|
Ck45 |
660 σN/mm2 |
630σsN/ mm2 |
4δs% |
207HB |
|
ST52 |
580σ N/mm2 |
420σsN/ mm2 |
10δs% |
190HB |
|
27SiMn |
840σ N/mm2 |
805σsN/ mm2 |
7.5δs% |
230HB |
Dimension?tolerance
|
ID size |
ID deviation (mm) |
|||
|
H7 |
H8 |
H9 |
H10 |
|
|
30 |
+0.021 0 |
+0.033 0 |
+0.052 0 |
+0.084 0 |
|
>30~50 |
+0.025 0 |
+0.039 0 |
+0.062 0 |
+0.100 0 |
|
>50~80 |
+0.030 0 |
+0.046 0 |
+0.074 0 |
+0.120 0 |
|
>80~120 |
+0.035 0 |
+0.054 0 |
+0.087 0 |
+0.140 0 |
|
>120~180 |
+0.040 0 |
+0.063 0 |
+0.100 0 |
+0.160 0 |
|
>180~250 |
+0.046 0 |
+0.072 0 |
+0.115 0 |
+0.185 0 |
|
>250~315 |
+0.052 0 |
+0.081 0 |
+0.130 0 |
+0.210 0 |
|
>315~400 |
+0.0527 0 |
+0.089 0 |
+0.140 0 |
+0.230 |
