4 in 4 Out HDMI Routing Matrix - DY-HDMI-MX02

PRODUCT INFORMATION

4 in 4 out HDMI Routing Matrix

Model No: DY-HDMI-MX02

Price : $440/PCS for 50PCS, $430/PCS for 100PCS, $420/PCS for 300PCS.

----------------------------------------------------------------------------------------

Introduction

This 4X4 Matrix HDMI SWITCH SPLITTER by cat5e/6 offers unprecedented flexibility and convenience by routing high definition audio/video from any of four HDMI video sources to any of 4 displays over HDMI cable or 4 remote displays over inexpensive, standard CAT5e/6 cable. It eliminates the need to disconnect and reconnect sources to a display equipped with one input.

Four receivers work with the Switch Splitter as a full functional module. Full High-Resolution HDTV signals are supported up to a resolution of 1080p over HDMI cable 15m or at a maximum distance of .40M over two pieces of CAT5e/6 cable. The 4X4 Matrix HDMI SWITCH SPLITTER works with HD-DVD players, TiVo systems, HT PCs, and satellite set-top boxes that connect to an HDMI display. Every source and display is accessible at all times by selecting it with an IR remote or through RS232 port.

Features:
1. Easy to Use: Install in seconds, no need for setting.
2. Allows up to four HDMI video devices to be independently switched to four HDMI monitors, HDTVs or projectors.
3. The four outputs could show the same or different source at the same time no matter the source is HDCP or not.
4. Delivers uncompressed digital video with zero signal loss.
5. Support high definition resolutions 1080p, 1080i, 720p and standard video format.
6. Triple switching modes, auto, IR remote and manual.
7. With extra infrared receiver extension.
8. Remote control function via RS232 or Ethernet.
9. HDCP compliant.
10. Extra Digital Audio in the form of RCA and Toslink to each HDMI output, allows independent audio to be connected into AV receiver.
