2.5"SATA HD media player Recorder with Network,SD/MMC Card reader/HOST

2.5"SATA HD media player Recorder with Network,SD/MMC Card reader/HOST

Model No: DVR-X3

1. Features:

1).Super record function, support one-key record and timing record.

2).With built-in 2.5-inch SATA Hard Disk interface. Innovative hard disk installation method and users can easily and conveniently dismantle/install hard disk, in no need of removing the shell.

3).Mainly support the following video coding formats: H.264, MPEG1/2/4, Xvid, Divx and VC1, Support all common video container formats: MKV, MOV, AVI, ISO, WMV, ASF, MP4, TS, M2TS, FLV, DAT, VOB, MPG, with maximum resolution up to 1080P.

4).Fully support 720P HD RM/RMVB video, decoding ability up to 1280 x720, taking all online movies and TV plays in the format of RMVB at one haul of the net.

5).Support music in the formats of MP3, WMA, OGG, AAC, etc., and especially support non-destructive Music formats (FLAC, APE, WAV), bringing music lovers to high-quality enjoyment.

6).Support picture formats (JPEG, BMP, PNG, GIF, and TIFF), with pictures enlarged, rotated and displayed (by NORMAL).

7).Support subtitles in various formats (SMI, ASS, SSA, SRT, SUB, SUB+IDX).

8).Support the functions of copying/pasting/deleting files from/on/between devices, and facilitating file management.

9).Support LAN, allow to directly opening movie, music and picture files shared on LAN-based computer, in no need of installing any other software, alleviating the sufferings of installing software, simple and easy.

10).Support NAS function, allowing to the remote file transfer through the network, and acting as a network disk.

11).Act as a monitor equipment, and monitor home/garage/staircase, etc. through adding a camera.

12).Adopt advanced capacitive touch key. Touch key does not require a mechanical contact of traditional mechanical touch key, or any avoiding the potential safety problems caused by body directly contacting with sheet metal. Reliable and durable, beautiful and stylish!

2. Product specifications:

1).Power: positive outside and negative inside,100V-240V~50/60HZ,5.5V/3A

2).Dimensions: 147x45x200mm

3).File system: FAT32, NTFS

4).VIDEO OUT: AV, HDMI1.3

5).VIDEO IN: AV IN

6).AUDIO OUT: L/R stereo, coaxial

7).Video format: MP4, MOV (.mp4, .mov, .xvid, .m4v), AVI (.avi, .divx), DVD Video (.iso),

WMV (.asf, .wmv, .xvid), MKV (.mkv), TS, DAT, MPG, MPEG (.dat, .mpg, .mpeg),

VOB (.vob), RM, RMVB (.rm, .rmvb)

8).Video Coding: DivX, MPEG4, MPEG1, DivX, MPEG4.H.264, VC1, MPEG1, MPEG2, MPEG4, VC1,WMV9, DIVX, H.264 (1920*1080P), RV8, RV9 (1280*720P)

9).Audio format: MP3/WMA/WAV/OGG/FLAC/APE/DTS/AAC/AC3

10).Picture format: JPEG, BMP, PNG, GIF

11).Subtitle format: SMI/ASS/SSA/SRT/SUB/SUB+IDX

12).Video-recording parameter: file format: AVI; video coding: H.264;

Audio coding: PCM; resolution: 720X576

13).External port: 2ports USB HOST, USB-PC, SD card, HDMI, AV IN, AV OUT, coaxial, network

14).Output resolution: PAL/NTSC/720P/1080P

Accessories:

Remote controller x 1pcs,  AV Cable x 2pcs,  HDMI Cable x1pcs  (Optional) , USB Cable x 1pcs,

Power supply x 1pcs,  User Manual x 1pcs
