Home > Products > AAC Weighing System > Electric Cement Powder Scale container AAC Weighing system for weighing lime before mixing
Electric Cement Powder Scale container AAC Weighing system for weighing lime before mixing
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
FW sensor Electric Slurry Scale AAC Weighing system for measuring the powder
-
Industrial Professional Electric Water Scale AAC Weighing system for AAC production line
-
2m Aluminum Powder AAC Mixer composed of mixing drum / mixing fan / gear box
-
AAC production line Pouring Mixer for mixing concrete body before casting
-
AAC Block production line Horizontal AAC Cutting Machine , Steel wire for horizontal cutting 0.6mm
-
Autoclaved Aerated Concrete plant AAC Cutting Machine , Vertical cutting machine
Product Details
| Brand Name | SANKON | Place of Origin | China | |
Product Description
Certification:GMC,ISO
Electric Cement Powder Scale
Description:
a) ?Uses
Cement?scale?is?a?container?for?weighing?lime?before?it?putted?into?pouring?mixer
b) ?Technical?Parameter
1, MAX?DIMENSION
length:1560mm???width:1780mm???height:1960mm
2, weight:630kg
3, capacity:1000kg
4, sensor?type:“TSB”
5, pneumatic?butterfly?valve:D671J-10-300
c) ?Structure
The meter is composed of chamber, support ring, load sensor and pneumatic butterfly valve.
The drum shapes like a truncated cone, which makes a quick discharge. It is made by rolling steel.
The support ring is made of steel and there is chamber on the top and the support ring below it, and there are
?3 load electrical sensors hang among the chamber and support ring, and there is pneumatic butterfly valve in the discharge drum to control the program.
d) ?Work?Principles
When the cement is fed into the chamber, the electrical sensor will transfer the weight to the display automatically,
and it will output the signal to the computer. The discharge is controlled by the pneumatic valve.
e) ?Quick-wear?parts
|
no |
name |
type |
remark |
|
1 |
sensor |
TSB-1000 |
|
|
2 |
pneumatic?butterfly?valve |
DN300 |
