Flyash / Sand AAC Block Plant , 50,000m to 400,000m annual capacity

Flyash/Sand AAC Block Plant /50,000m3 to 400,000m3 annual capacity

1.1 Introduction

Autoclaved Aerated Concrete (AAC) Block, also called Light Block, used siliceous (fly ash, sand and, slag) And calcareous (lime & cement) as the main raw materials, which through the process of batching, pouring, curing, cutting, autoclaving, separating and packing to make into the final products. It is new type & environmental construction material and widely used for industry and civil building construction.

AAC Block is the most mature technology of production and application in the worldwide nowadays.

1.2 National Standard

The People’s Republic of China Standard: GB/T 11968-1997

1.2.1 Standard

The items of the below standard content, after the cited in this standard then form the items of this standard. While the publication of this standard, this standard are the valid standard. All the standard must be revised, while use every aspect of this standard should discuss the possibility of the latest version.

GB9196-88 mix the industry waste residue building material radioactivity substance control standard.

GB10294-88 heat insulation raw material steady-state thermal resistance

And the related characteristic test: guarded hot plate apparatus

GB/T11969-1997 autoclave aerated concrete block performance test method general rule.

GB/T11970-1997 autoclave aerated concrete block bulk density, moisture content

And water absorption test method.

GB/T11971-1997 autoclave aerated concrete block mechanical performance test method.

GB/T11972-1997 autoclave aerated concrete block drying shrinkage test method.

GB/T11973-1997 autoclave aerated concrete block frost resistance test method.

JC/T790-85(96) brick and block terms

1.2.2 The specification and size of the block see form No.1.

Form No.1 Block Specification and Size (mm)

Note: if purchaser needs other specification, they should negotiate with manufacturer.

1.2.3 The block can be classified according to the compressive strength and bulk density.

The compressive strength includes: A1.0, A2.0, A2.5, A3.5, A5.0, A7.5, A10

The bulk density includes: B03, B04, B05, B06, B07, B08

1.2.4 The block can be divided into three grades according to measurement tolerance, appearance, bulk density and compressive strength: High quality degree (A), first-class degree (B), qualified degree(C).

1.2.5 Block Product Mark

Autoclaved aerated concrete block with the density degree A3.5, bulk density degree is B05, high quality product, specification and size 600mm*200mm*250mm, the mark is: ACB A3.5 B05 600*200*250A GB11968.

1.2.6 Technical Requirement
