Lux Control 1 - 10v Dimming Microwave Motion Sensor 12M Mounting Height MC003V R DE

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Merrytek		Place of Origin	China
Model Number	MC003V R DE

Product Description

Delivery Time:1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Certification:CE & R&TTE

Lux Control 1-10v Dimming Corridor Function Microwave Motion Sensor 12 M Mounting Height MC003V R DE With Daylight Sensor Plastic Housing?

Description:

? 12M mounting height for huge space application . ? Attachable version ,wish mini sensor detector . ? Built-in adjustable daylight sensor. ? Lux Control motion sensor .will switch off the light when with sufficient ambient light level . ? Automatic switch on - off and dimming based on motion and ambient light level . ? 1-10V interface can match up with Merrytek stand-alone daylight sensor MS01 and achieve daylight harvesting. ? 4-pole press-in terminal (L,N,N,L′),easy assembly. ? Compact size makes it suitable to fix within most luminaries ? Detection area, time delay and daylight threshold can be precisely set via DIP switch. ? Wide detection area, range up to 16m in diameter. ? The sensors allow energy saving without compromising comfort. When used in combination with 1-10V dimmable LED drivers or ballasts, they can achieve 3-step dimming function, which is perfect for use in some areas that requires a light change notice before totally switch off.

Specifications:

Operating voltage	220-240Vac, 50Hz
Rated load	800W(inductive), 1200W (resistive)
HF system	5.8GHz±75MHz, ISM wave band
Power consumption	≤0.5W(standby), <1W(operation)
Transmitting power	<0.5mW
Detection zone Max.(D x H)	16m x 12m
Motion detection	0.5~3m/s
Detection angle	150°(wall installation) 360°(ceiling installation)
IP rating	IP20
Operation? Temperature	?-35℃~70℃
Hold time	10s/30s/90s/3min/20min/30min
Detection sensitivity	10% / 25% / 50% / 75% / 100%
Daylight sensor	5lux / 15lux / 30lux / 50lux / Disable
Stand-by period	5s / 5min / 10min / 30min / 1h / Disable
Stand-by dimming level	10% / 20% / 30% / 40% / 50%
Life time	50,000 hours
Guaranty	5 years

Applications:

Stairwell, Corridor, Gas Stations, Parking lot , Warehouse ,etc
