Power Free Dry Contact Motion Sensor MC016D 5.8GHz 75MHz , ISM Wave Band

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Merrytek		Place of Origin	China
Model Number	MC016D

Product Description

Delivery Time:1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Certification:CE , R&TTE

Dry contact DC 12Vdc input Microwave motion sensor MC016D, CE & R&TTE

Description

? Dry contact design ? Voltage free sensor and load are in different power supply system ? Esp. for solar energy garden lamp and industrial application ? Dry contact works in normally closed mode and normally open mode ? ISM Band 5.8GHz ? Automatic switching based on motion and ambient light level ?3 pole relay design, user can choose normally open mode or normally closed mode ?according to different application ?Sensor data can be simply set via DIP switch. ?Wide detection area, range up to 16m in diameter. The sensor can be detected through plastic, glass and thin non-metal materials. It supplies dry contacts in normally closed mode and normally open mode. Dry contact means open or close relay without any current or voltage. It is perfect for the solar energy garden lamp or industrial control application where requires isolation between motion signal and power supply

Function:

ON-off function

Specifications:

Operating voltage	12Vdc
Rated load	Power free
HF system	5.8GHz±75MHz, ISM wave band
Power consumption	≤0.5W(standby), <1W(operation)
Transmitting power	<0.5mW
Detection zone Max.(D x H)	16m x 6m
Motion detection	0.5~3m/s
Detection angle	150°(wall installation) 360°(ceiling installation)
IP rating	IP20
Operation Temperature	-20℃~50℃
Hold time	10s/ 30s/ 90s /3min/20min / 30min
Detection sensitivity	10% / 25% / 50% / 75% / 100%
Daylight Sensor	5lux / 10lux / 30lux / 50lux /Disable
Life time	50000 hours
Guaranty	5 years

Applications:

Stairwell, Corridor, Balcony, Pathway, etc.
