Product Details

Brand Name	jingke		Place of Origin	China
Model Number	JK-4050

Metal CNC router
1.suitable for metal mould milling
2.DSP control
3.Taiwan linear guide
4.Germany ball screw

JK-4050 Metal CNC router

Usage:can be used to carve letters or designs and work mould on iron, steel, bronze,aluminum and so on.

Machine features:

Particular style,competent for elaborate engraving and cutting.

Structure:cabinet,convenient,durable

Speed:quicker,2-3 times faster than normal one.

Design:human,easy operation

Powerful:adapt for many fields.

Economic:high quality with reasonable price,economic.

Parameters:

Modle	JK-4050
Machine body	whole cast iron
Work dimensions	400×500mm
Body dimensions	1100×1500×1500mm
X/Y/Z movement	Precision ball screw/Germany
Guide	Linear square rail/Taiwan
Z-axis working area	120mm
Max feeding height	100mm or bigger
Cut thickness of material	≤30mm
Max.speed	8000mm/min
Working speed	0-6000mm/min
Mechanical precision	0.01mm
Software	Type3,Artcut,Artcam software
Working voltage	AC 380V/50-60Hz,3 phase
Drive type	stepper motor
Spindle	3KW variable speed,water-cooled
Spindle speed	0-24,000rpm
Blade diameter	1-6mm
Control system	DSP
Command	HPGL.G code,u00,mmg,plt
