JK-1224 CNC Engraving Machine

FOB Price

USD $1.00 - $1.00 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	jingke		Place of Origin	China
Model Number	JK-1224

JK-1224 CNC Engraving Machine

Machine features:

1. Particular style, competent for elaborate engraving and cutting marble, granite and so on stone material.

2. The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.

4. NCSTUDIO or DSP control system can be chosen at your decision.

5. Be compatible with type 3, Artcut, Artcam software.

6. Memory to ensure the processing point when the blade is broken or postpone situation. Specific saving mode of different points.

7.This machine can do 2D and 3D products,that is, can do plane and relief designs on stone material.

Technical parameter:

MODLE	JK-1224
Work dimensions	1200 x 2400 x 80mm
Body dimensions	1500 x 2800 x 1500mm
Z-axis working area	80mm
Max. Feeding height	120mm or bigger
Cut thickness of material	40mm
Max. Speed	6000mm/min
Working speed	0 - 4000mm/min
Mechanical precision	0.01mm
Software	Artcam, Artcut, Type3 software
Power source	AC 220/50Hz
Driver type	stepper motor
Spindle	3KW variable speed, water-cooled
Spindle speed	0 - 24,000rpm
Blade diameter	1 - 6mm
Control system	DSP
Command	HPGL,G code, u00, mmg, plt
N.W.	700KG.
G.W.	780KG
