Durable Post Cutting Roof Panel Roll Forming Machine Double Layer 0.3mm - 0.8mm
Negotiable
/ Unit
1 Unit(Min.Order)
- 0 Unit / Units per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Trimdeck Chromedeck Sheeting Roof Panel Roll Forming Machine Yield Strength G550
-
Metal Elbow Pipe Downspout Machine with PLC Panasonic Control System
-
Standing Seam Roof Panel Roll Forming Machine with Chain Transmission
-
Custom PU Foam Roller Shutter Door Forming Machine with 45 # Forged Steel Shaft
-
Fire Resistant Cold Room PU Sandwich Panel Machine / Polyurethane Sandwich Panel Line
-
380V 3ph Carbon Steel C & Z Purlin Roof Roll Forming Machine 30KW
Product Details
| Brand Name | RISHBIN | Place of Origin | China | |
Product Description
Certification:CE
Durable Post Cutting Roof Panel Roll Forming Machine Double Layer 0.3mm - 0.8mm
Specifications?of?Double Layer Roof Panel?Roll Forming Machine
| Product Name | Item | Description |
| Double Layer Roll Forming Machine | Production Material? | Thickness(0.3mm-0.8mm), yield strength≤G250MPa |
| Forming speed | 10-15 m/min | |
| Number of stations | Upper layer: 13 stations | |
| Lower layer: 15 stations | ||
| Roller material | GCr15 with heat treatment and hard chrome-plated HRC58-62 | |
| Shaft diameter | 76mm | |
| Shaft material | High-quality steel 45 quenched and tempered after finishing treatment | |
| Main motor power | 5.5 kw | |
| Power of hydraulic station | 3.0 kw | |
| Electronic controlling system | Full-frequency PLC controlling system | |
| Cutting | Cutting after forming with hydraulic driving | |
| Material of cutting blade | Cr12 quenched |
Structure of?Double Layer Roof Panel?Roll Forming Machine
This roll forming machine consists of 5 tons passive decoiler, forming machine, hydraulic cutting device, computerized control cabinet and stacker.
Working Process
Coiler loading → feeding-in with guiding (metal sheet is guided into the first forming station) → rolling & forming → cutting → stacker running out
Production Line Sketch
Sample Drawing
Upper
Lower
Our Advantage ??
High Quality Reliable? Durable Reasonable Price Good after Service 1 Year Warranty More Than 10 Years ExperienceMore?information?about?steel?roof?panel?profiles,?Pls?contact?with?us!
