Product Details
| Brand Name | Zhongyuan | Place of Origin | China | |
| Model Number | 914mm width |
Product Description
Certification:CE
0.2mm Thickness Corrugation Sheet Metal Roll Forming Machines 72mm Shaft Diameter
Technical data of Corrugation Sheet Roll Former
|
Suitable material |
Q235 color steel sheet;0.2mm thickness |
|
Forming speed |
about 20m/min |
|
Power Requirement |
Main motor power: 7.5 Kw(Depend on final design) |
|
Hydraulic station power: 2.2Kw(Depend on final design) |
|
|
Material of forming rollers |
No.45 steel, plated with chrome on sureface. |
|
Material of cutter |
Cr12 mould steel with quench treatment, HRC58-60 |
|
Material of shaft |
High quality 45# steel with heat treatment. Roller grinder milling. |
|
Shaft diameter |
72mm |
|
Controlling system |
Mitsubishi PLC & converter |
|
Total weight of machine |
About 7000KGS |
|
Machine’s size |
about 15m×1.8m× 1.5m (Depend on final design) |
Layout of?Corrugation Sheet Roll Former
Product application of Corrugation Sheet Roll Former
The product from roof forming machine are widely used roof of fabrication building, such as the roof of garden, factory, hotel, exhibition center and villa,etc.
Our Corrugation Sheet Roll Former’s advantages
1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .
2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.
3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.
4. High precision: shafts for rollers are tooled by grinding machine at least twice. Rollers are CNC processed to ensure precision performance.
5. People originate: introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction.
6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.?
7. All-in-house?source: We are?\"All-in-house?source\" factory to ensure quality and delivery of your machines.
8. Long life: Ensure you our produce machine’s?lifetime more than 15 years.
Certificate: ISO?9001,?CE,
