Cold Storage EPS Roof Sandwich Panel Insulation High intensity

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Zhongyuan		Place of Origin	China
Model Number	970mm width

Delivery Time:within 15 days

Cold Storage EPS Roof Sandwich Panel Insulation High intensity?

EPS sandwich panel’s Feature

1. Light weight: installation is easy and flexible thanks to its light weight, only 10-18kg/㎡.

2. High intensity and large rigidity ensures suitability for weight-bearing structures.

3. Temperature retention and heat insulation: good thermal insulation. ?

4. Excellent sound insulation performance.

5. Pleasing appearance and durable.

6. Product thickness available: Mini thickness: 40mm (roof corrugated sandwich panel)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?50mm (wall panel)

Max. thickness: 150mm(exclude corrugated sandwich panel)?

Sandwich Panel Specification:

Effective width	Wall panel: 950mm 1150mm； Roof panel: 970mm
Length	According to customer\'s request
Materials	Polystyrene foam board(EPS), Color steel sheet
Structure	Upper and lower layer: Color steel sheet
Middle: polystyrene foam board or polyurethane foam board
Thickness	Color steel sheet: 0.3-0.7mm?? Polystyrene foam board: 50mm 80mm 100mm 150mm
The polystyrene density	8-30kg/m3
Conventional color	Ocean blue, tephrosious or as per client’s requirement
Character	Light in weight, heat insulation, water resistant, green and environmental
Use	various roofs and walls referring to the large size factory buildings, storages, exhibition halls, gymnasiums etc.

Engineering Example

Our EPS sandwich panel’s advantage

All-in-house?source: We are?\"All-in-house?source\" factory to ensure quality and delivery of sandwich panels.
