7.5 KW Color Steel Eaves Trim Roof Panel Roll Forming Machine Chain Transmission

?
Quick?Detail
?
Rishbin?was founded in 1999. With more than ten years\' development, now it becomes a leading professional supplier in the field of?roll forming machinery?industry, and exports its quality production line

to the markets all over the world.

Our?roof?panel?roll?forming?machines?are?special?for?manufacturing?high?quality?steel?roof?&?wall?cladding?

panels,?aluminum?Lock?Roofs.?With?our?engineer’s?many?times?improvements,?the?Ribbed?Roof?Panels?

machine?design?is?perfect.?The?Ribbed?Roof?profile?surface?is?smooth?and?power?fee?is?lower,?driven?by?

chain.
?
It?is?specially?designed?forming?roofing?corrugated?sheet,?wall?panel,floor?deck,?under?mass-production.?The?highest?speed?of?the?line?can?reach?to?30?M/min?working?with?fully?automaticlly?stacking?system.
?
?
Composition of?color steel eaves trim roof panel roll forming machine

Roll?forming?main?machine……………………………1?unit
Manual?Un?coiler………………………………………?1?unit
Control?panel…………………………………………..1?unit
Hydraulic?station……………………………………?…1?unit
Manual?out?table………………………?……………….2?units

Specifications?of?color steel eaves trim roof panel roll forming machine
?
1:?Coil?width:?depend?on?profiles?
2:?working?speed:?12-15m/min?(not including?cutting)
3:?roll?station:?about?10?stations
4:?material?of?roller:?grade?45?steel,?polished?and?coated?with?chrome?
5:material?of?main?shaft:45﹟?steel???diameter?roller:?Ф70mm
6:?main?power:?7.5KW???
7:?forming?thickness:?1.0mm?zinc?and?color?steel,?250Mpa-G550MPA
8:?Transmission:?by?single?Chains?1.5inch?
9:?feeding?and?guide:?surface?polished?and?coated?with?chrome
10:?machine?drive?parts?adopt?protect?cover?
11:?machine?adopt?new?station?with?chrome?
12:?size?of?main?machine:?7500x1500x1300(mm)???L?x?W?x?H?need?1x40GP?container
13:?weight:?about?6000Kgs

?
Technological process of?color steel eaves trim roof panel roll forming machine
?
De?coiler—feeding &?guiding---roll?forming----cut?to?length—Out?table
?
Sample Drawing
?

?
