KRF 102 296/1 R1B GSM Wireless Base Station Ericsson BTS RBS6201 RUS01B0

RBS6201

BFM?901?290

BFM?901?290?R6A

Cabinet

DUG?20?01

KDU?137?569/1

KDU?137?569/1?R2B

KDU?137?569/1?R2D

KDU?137?569/1?R3C

KDU?137?569/1?R3D

KDU?127?161/2?R4C

KDU?127?161/2?R4E

RBS6201?The?main?control?unit,Can?also?be?used?for?

RBS6601?DUG?20?01+SUP6601=MU,Supports?up?to?

12TRX.

PCF?02?03

KFE?101?1157/4

KFE?101?1157/4?R1F

KFE?101?1157/4?R1H

The?power?supply?connection?filtering,?connected?to?

an?external?-48V?DC?to?RBS?cabinet.

PDU?02?01

BMG?980?336/4

BMG?980?336/4?R2C

BMG?980?336/4?R2G

BMG?980?336/4?R2H

PDU?(equivalent?to?IDM)?assigned?to?other?units?-48V.

PFU?02?01

KFE?101?1162/2

KFE?101?1162/2?R1D

Filter?in?RBS,?-48V,?DC?system?voltage?stability.

RUS?01?B0

KRF?102?296/1

KRF?102?296/1?R1B

900M?carrier?module,Supports?up?to?4?carrier.

RUS?01?B3

KRY?901?119/1

KRY?901?119/1?R1E

1800M?carrier?module,Supports?up?to?4?carrier.

RUS?02?B0

KRC?161?263/1

KRC?161?263/1?R1K

900M?carrier?frequency?module,?supports?up?to?

8?carrier.

SAU?01?01

ZHY?601?17/1

ZHY?601?17/1?R1D

Installed?in?the?DM?box,?expand?external?alarm?to?

32?Road.

SCU?02?01

BGM?136?1006/2

BGM?136?1006/2?R2A

1.To?provide?external?alarm?interface;

2.To?the?fan?power?supply;

3.To?control?the?fan?to?adjust?the?temperature?in?the?

cabinet?Voltage?alarm;

4.PMU?monitoring.

SHU?02?01

BGK?901?18/2

BGK?901?18/2?R1B

BGK?901?18/2?R1D

The?monitoring?information?of?each?unit?in?the?

cabinet?of?centralized?forwarding?to?the?main?control?

DUG,?connected?to?an?external?unit?such?as?PDU,?

SCU?to?DU.
